Closed loop hydraulic pump/hydraulic motor manufacturer & hydraulic solutions provider - Highland Hydraulic

Variable Displacement Axial Piston Pump 42mpa - - Highland Hydraulic-1 1

Variable Displacement Axial Piston Pump 42mpa - - Highland Hydraulic-1 2

Variable Displacement Axial Piston Pump 42mpa - - Highland Hydraulic-1 3

Variable Displacement Axial Piston Pump 42mpa - - Highland Hydraulic-1 4

Variable Displacement Axial Piston Pump 42mpa - - Highland Hydraulic-1 5

Variable Displacement Axial Piston Pump 42mpa - - Highland Hydraulic-1 6

Variable Displacement Axial Piston Pump 42mpa - - Highland Hydraulic-1 7

Variable Displacement Axial Piston Pump 42mpa - - Highland Hydraulic-1

Payment Terms:

T/T, Western Union

Inquiry

Type

Axial piston pump

Pressure

42mpa

Brand

HIGHLAND

Operation Mode

Closed Circuit Hydraulic System

Product details of the variable displacement axial piston pump

Product Specification

Brand: HIGHLAND

Pressure: 42mpa

Operation Mode: Closed Circuit Hydraulic System

Type: Axial piston pump

Quick Detail

Highland Hydraulic variable displacement axial piston pump is designed by a team of professionals who have extensive industry knowledge and clearly know customer needs. With its unique style and sophisticated technology, the performance variable displacement axial piston pump has been magnified. Highland Hydraulic's variable displacement axial piston pump can meet the different needs of customers. Over the years, Shandong Highland Hydraulic Seiko Co., Ltd has expanded its strong positions in variable displacement axial piston pump field.

Product Description

Highland Hydraulic's variable displacement axial piston pump has more advantages over similar products in terms of technology and quality.

hEAVY DUTY CONCRETE MIXER SPV23 HYDRAULIC PISTON PUMP

SPV23 Hydraulic Piston Pump is a high-performance solution for concrete mixers, offering durability, efficiency,

and reliable operation. It ensures smooth mixing performance in demanding construction environments.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

SPV23 Hydraulic Piston Pump is engineered for high-performance concrete mixing applications. Ensuring efficient and precise mixing operations, built for durability, it withstands high-pressure demands and continuous operation in tough construction environments. Its advanced hydraulic technology minimizes energy consumption while maximizing output, making it a reliable choice for concrete mixers in large-scale projects.

Product Features

SPV23 Hydraulic Piston Pump is specifically designed for concrete mixers, providing powerful and efficient hydraulic performance.
High-pressure capacity and durable construction make it ideal for demanding construction applications.
With advanced engineering and precision manufacturing, the SPV23 pump offers extended service life, minimizing downtime and maintenance costs.
Its compact and robust design allows for easy installation, making it a preferred choice for concrete mixing equipment.

Product INTRODUCTION

SPV23 Hydraulic Piston Pump is a robust and efficient solution for concrete mixers, designed to handle extreme working conditions. Its high-pressure capabilities ensure mixer high efficiency performance. Hydraulic pump’s durable materials and precise engineering provide long-lasting reliability with minimal maintenance. Suitable for heavy-duty applications, it improves overall efficiency and operational stability in construction projects.

PRODUCT SPECIFICATIONS

Rated displacement			20	22	23	110
Rated displacement	Maximum displacement	ml/r	33.3	69.8	89	110.8
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3200	2700	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	342.6	432.9	535.3
Torque	Maximum output torque	Nm	227	480	606	749
Power	Continuous Power	KW	41	98	128	137
Power	Maximum power	KW	57	105	138	159
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	PV series hydraulic pump Hydraulic oil drainage	kg	45	63	79	79

PV20

PDF

PV22

PDF

PV23

PDF

PV110

PDF

detail displaY

SPV23 Piston Pump

SPV23 Hydraulic Piston Pumps

Concrete Mixer Hydraulic Piston Pump

Mixer Hydraulic Piston Pump SPV23

Product Application

6-12 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

About Us

Shandong Highland Hydraulic Seiko Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with more than 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.

Packing & Delivery

To protect hydrostatic pump, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.

What is the supply ability for the Hydraulic Piston Pumps?

The supply ability for the Hydraulic Piston Pumps is 200 Sets per month.

Company Introduction

As a comprehensive enterprise, Shandong Highland Hydraulic Seiko Co., Ltd covers a business range in production, processing, sales and service. And our main product is Hydraulic pump、Hydraulic motor、Hydraulic test benches. Highland Hydraulic has built a service system that meets the needs of consumers. It has won wide acclaim and support from customers. If you have any questions, feel free to consult us.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
