Hydraulic Pump Mode

HPV110

Function

Power components of hydraulic system

Operation Mode

Closed Circuit Hydraulic System

Product details of the swash plate piston pump

Product Specification

Hydraulic Pump Mode: HPV110

Operation Mode: Closed Circuit Hydraulic System

Function: Power components of hydraulic system

Product Introduction

The improved design of Highland Hydraulic swash plate piston pump reduces quality problems from the source. Durability: It has been given a relatively long lifespan and can retain somewhat functionality and aesthetics after long-time application. The product achieves good results in practical applications.

Superior Quality High Pressure Axial Piston Pump

With Advanced Technology

High-pressure axial piston pump is designed for maximum efficiency, durability, and precise fluid control. With advanced technology, it ensures stable operation and reliability in industrial, construction, and hydraulic applications.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

HPV110 Axial Piston Pump excels in delivering robust hydraulic performance under extreme pressure conditions. Its compact, adaptable layout ensures effortless integration into various system configurations. Featuring advanced sealing technology and reinforced internal components, the LPV70 guarantees minimal internal leakage, stable efficiency, and prolonged service life, perfectly suited for high-demand hydraulic applications in construction, mining, and industrial equipment.

Product Features

High-pressure axial piston pump is engineered for superior efficiency and longevity.
With cutting-edge technology, it optimizes fluid flow, minimizes energy consumption, and enhances operational stability.
Its robust construction ensures durability under extreme conditions, making it suitable for heavy-duty applications.
Featuring precision engineering and innovative design, it offers smooth operation, reduced noise levels, and excellent thermal stability.

Product INTRODUCTION

HPVseries is optimized for superior operational efficiency, featuring precision-machined components that reduce internal friction and energy loss. This efficiency translates to lower operating costs and improved productivity in heavy-duty applications.

Product specification

Rated displacement			30	50	70	90	110	130
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
Torque	Maximum output torque	Nm	227	353	480	606	749	885
power	Continuous Power	KW	41	72	98	128	137	162
power	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

HPV30(50)

PDF

HPV70（90）

PDF

HPV110(130)

PDF

detail displaY

High Pressure Axial Piston Pump

HPV70 Hydrostatic Piston Pump

High Pressure Axial Piston Pump

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To protect the goods, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.

Company Feature

• Based on the principle of 'customer first', Highland Hydraulic is committed to providing quality and complete service for customers.
• Our company attaches great importance to the staff training. After training, we have established a team of outstanding talents. They are high in education level and strong in professional ability.
• Highland Hydraulic's sales network covers from many provinces and cities to regions across the country.
• Highland Hydraulic is located in a place with beautiful environment and traffic convenience.
Customers who need our products are welcomed to contact us for consultation.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
