LPV Series Hydrostatic Pump For Construction Machinery

* Swash plate pump adjusts flow, direction with angle in closed loop systems.

* Highland specializes in axial piston pumps, easy to operate.

* Mechanical servo control stabilizes displacement, returns to center when handle released.

* Internal gear refill pump.

* German skeleton oil seal minimizes leakage.

* Servo valve integrates pressure control, remote systems.

* Axial piston pumps easy to maintain, disassemble/reassemble with tools.

MOQ:

1 sets

Packaging Details:

Plywood case

Delivery Time:

15 DAYS FOR SMALL BATCH, 60 DAYS FOR MORE THAN 100 SETS

Payment Terms:

T/T, Western Union

Supply Ability:

100 sets per month

Certificate:

CE ISO9001

Inquiry

Write a Review

Pressure

35mpa

Brand

HIGHLAND

Dimension(L*W*H)

53*34*43cm

Speed

2900r/min

Operation Mode

Closed Circuit Hydraulic System

Working Medium

Hydraulic Oil

Warranty

1 Year

Material

Cast Iron

LPV Series Hydrostatic Pump For Construction Machinery

Variable displacement hydraulic pump for closed loop operation

Products Advantages

LPV series closed axial piston pump offers high efficiency, compact design, and long service life, making it the ideal choice for reliable hydraulic systems.

LPV Series Hydrostatic Pump For Construction Machinery 10

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

LPV Series Hydrostatic Pump For Construction Machinery 11

Low price

We promise the lowest price for new products of the same variety in the world

LPV Series Hydrostatic Pump For Construction Machinery 12

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Application

The LPV series closed axial piston pump is ideal for applications requiring a reliable and efficient hydraulic power source. Whether it's for industrial machinery, construction equipment, or agricultural vehicles, this pump delivers outstanding performance in demanding environments.

6-20 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground LHD

mining loader

Curb Stone Forming Machine

Harvester

Forage Silage Harvester

Cane Grabber Machine

Product Specifications

Rated displacement			30	50	70	90	110	130	160	180	200
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130	160	180	200
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700	2400	2400	2400
	Rated speed	r/min	2500						2200
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4	776	875	972
Torque	Maximum output torque	Nm	227	353	480	606	749	885	1000	1098	1200
Power	Continuous Power	KW	41	72	98	128	137	162	191	224	279
Power	Maximum power	KW	57	87	105	138	159	188	292	307	318
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	LPV series hydraulic pump Hydraulic oil drainage	kg	44	45	62.5	63.5	71	96	98	140	144

LPV30（50）

PDF

LPV70（90）

PDF

LPV110

PDF

LPV130（160）

PDF

LPV180（200）

PDF

Product Description

Experience reliable and efficient hydraulic power with our LPV series closed axial piston pump. Designed for smooth operation and long-lasting performance, it's the perfect choice for a wide range of industrial applications.

Product Features

* Product design: simple and easy to dismantle, high strength and high pressure resistance, easy to install in series, full range

* Control mode: manual servo, electric proportional servo, hydraulic servo, control valve can be modularized replacement

* pump installation interface design in line with international standards, easy to install and operate

* Commitment to the world's lowest prices for new products of the same variety

* Can be customized according to customer's needs.

Product Details

Its closed axial piston design, it provides reliable performance and long service life. Its compact size makes it ideal for installations where space is limited.

LPV130（160）-2

LPV180（200）-1

LPV180（200）-2

FAQ

What are the typical applications for the HPV110/130-MA-R/L-23 Closed Axial Piston Pump?

The HPV110/130-MA-R/L-23 Closed Axial Piston Pump is commonly used in industrial and mobile hydraulic systems, including construction equipment, agricultural machinery, and material handling equipment.

What makes the HPV110/130-MA-R/L-23 Closed Axial Piston Pump compact?

The compact design of the HPV110/130-MA-R/L-23 Closed Axial Piston Pump allows for easy installation in tight spaces and provides greater flexibility in equipment design and layout.

Can the HPV110/130-MA-R/L-23 Closed Axial Piston Pump handle high pressure applications?

Yes, the HPV110/130-MA-R/L-23 Closed Axial Piston Pump is designed to handle high pressure applications, making it suitable for demanding hydraulic systems.

What kind of hydraulic fluid is recommended for use with the HPV110/130-MA-R/L-23 Closed Axial Piston Pump?

The HPV110/130-MA-R/L-23 Closed Axial Piston Pump is compatible with a variety of hydraulic fluids, but it is recommended to use fluids that meet the manufacturer's specifications for optimal performance.

Can the HPV110/130-MA-R/L-23 Closed Axial Piston Pump be used in harsh environmental conditions?

Yes, the HPV110/130-MA-R/L-23 Closed Axial Piston Pump is designed to withstand harsh environmental conditions, including extreme temperatures, high humidity, and exposure to dust and debris.

How can I ensure proper maintenance of the HPV110/130-MA-R/L-23 Closed Axial Piston Pump?

Proper maintenance of the HPV110/130-MA-R/L-23 Closed Axial Piston Pump includes regular inspection, checking for leaks, monitoring fluid levels, and following the manufacturer's recommended maintenance schedule.
