Swash Plate Piston Pump 533443cm Wholesale - Highland Hydraulic

Inquiry

more products

Hydrostatic Pump

Hydrostatic Motor

Hydraulic Test Bench

Portable Hydraulic Tester

Send your inquiry

Hydraulic Pump Mode

PV23

Product Name

closed circuit hydraulic pump

Dimension(L*W*H)

53*34*43cm

Operation Mode

Closed Circuit Hydraulic System

Displacement

90ml/r

Product details of the swash plate piston pump

Product Specification

Operation Mode: Closed Circuit Hydraulic System

Displacement: 90ml/r

Product Name: closed circuit hydraulic pump

Dimension(L*W*H): 53*34*43cm

Hydraulic Pump Mode: PV23

Product Introduction

To manufacture Highland Hydraulic swash plate piston pump, we only work with the high-quality materials. This product meets the quality standards and is certified. This product is regarded as the remarkable one in the industry.

PV23 Concrete Truck Mixer Hydraulic Pump Manufacturer

HIGHLAND Hydraulic piston pump is a high-performance solution for construction equipment,

offering durability, efficiency, and precision. Designed for heavy-duty applications,

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

With simplified installation and easy maintenance features, PV23 piston pump reduces downtime, supporting uninterrupted operation and consistent hydraulic performance.

Variable Displacement Hydraulic Piston Pump

Product Features

Concrete mixer hydraulic pump is a high-performance axial piston component specifically developed for demanding mixer truck applications, delivering exceptional pressure stability and reliable fluid transfer.
Designed using precise manufacturing techniques, it achieves optimal durability, ensuring reduced wear and minimal downtime during intensive concrete mixing operations.
Widely adopted in concrete mixer trucks, it significantly enhances mixing efficiency, operational reliability, and overall equipment performance.

Product INTRODUCTION

PV23 hydraulic pump features advanced engineering and durable construction, ensuring optimal efficiency and exceptional reliability even under heavy-duty, continuous-operation conditions.

PRODUCT SPECIFICATIONS

Rated displacement			20	22	23	110
Rated displacement	Maximum displacement	ml/r	33.3	69.8	89	110.8
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3200	2700	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	342.6	432.9	535.3
Torque	Maximum output torque	Nm	227	480	606	749
Power	Continuous Power	KW	41	98	128	137
Power	Maximum power	KW	57	105	138	159
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	PV series hydraulic pump Hydraulic oil drainage	kg	45	63	79	79

Button

PV20

PDF

PV22

PDF

PV23

PDF

PV110

PDF

Product Details

Its closed axial piston design, it provides reliable performance and long service life. Its compact size makes it ideal for installations where space is limited.

PV20Mixer Hydraulic Pumps

PV22 Axial Piston Pumps

PV23Mixer Hydraulic Pumps

Product Application

Grape harvester

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Combine harvester

Agricultural machinery

Combine harvester

Special equipment
