Swash Plate Piston Pump 30-60 Work Days Wholesale - Highland Hydraulic

Company Advantages

· Highland Hydraulic swash plate piston pump passes through the extremely harsh quality control and inspection.

· Our swash plate piston pump are designed to cater to the unparalleled comfort for users.

· Shandong Highland Hydraulic Seiko Co., Ltd has strong new product development capabilities for swash plate piston pump and strong market competitiveness.

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Axial piston pump integrates advanced hydraulic technology to deliver superior pressure control and efficiency. Designed for maximum durability, it features a high-strength casing and wear-resistant components. With an optimized internal structure, it reduces friction and heat generation, ensuring stable performance in demanding environments. Its high-pressure capabilities make it ideal for precision-driven applications.

Product Features

• High-pressure axial piston pump is engineered for superior efficiency and longevity.
• With cutting-edge technology, it optimizes fluid flow, minimizes energy consumption, and enhances operational stability.
• Its robust construction ensures durability under extreme conditions, making it suitable for heavy-duty applications.
• Featuring precision engineering and innovative design, it offers smooth operation, reduced noise levels, and excellent thermal stability.

Product INTRODUCTION

Highland axial piston pump offers high efficiency, superior durability, and precise fluid control. It is designed for industrial, construction, and hydraulic applications that require stable, high-pressure operation. Its robust construction ensures long-term performance and reliability.

Product specification

Rated displacement			30	50	70	90	110	130
	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
	Maximum output torque	Nm	227	353	480	606	749	885
power	Continuous Power	KW	41	72	98	128	137	162
	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

HPV30(50)

PDF

HPV70（90）

PDF

HPV110(130)

PDF

detail displaY

High Pressure Axial Piston Pump

HPV70 Hydrostatic Piston Pump

High Pressure Axial Piston Pump

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To protect the goods, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

Company Features

· Ranking top in swash plate piston pump industry, Highland Hydraulic is popular in the market.

· Thanks to the support of QC team, the quality of swash plate piston pump can be guaranteed.

· In order to promote our better cooperation, Shandong Highland Hydraulic Seiko Co., Ltd is willing to do more things for our customers. Get quote!

Application of the Product

swash plate piston pump is one of the main products of Highland Hydraulic. With wide application, our product can be applied to different industries and fields. And it is deeply loved and favored by customers.

Before developing a solution, we will fully understand the market situation and customer's needs. In this way, we can provide effective solutions for our customers.

Product Comparison

Highland Hydraulic guarantees Hydraulic pump、Hydraulic motor、Hydraulic test benches to be high-quality by carrying out highly standardized production. Compared with other products in the same category, it has the following advantages.
