Axial Piston Pump Price Plywood Case by Highland Hydraulic

Product details of the axial piston pump price

Product Specification

Type: Axial piston pump

Working Medium: Hydraulic Oil

Application: Agricultural machinery,Walking machinery

Quick Detail

Latest machining techniques are used in manufacturing Highland Hydraulic axial piston pump price. axial piston pump price has excellent performance, stable and reliable quality. This product is now in high demand in the market and is taking up greater market share.

Product Introduction

Highland Hydraulic's axial piston pump price has better quality than other products in the industry, which is specifically shown in the following aspects.

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

High-pressure variable displacement pumps are built for closed-circuit systems, ensuring precise flow regulation and efficient power transmission. They provide smooth, responsive performance for demanding industrial and mobile applications. With a compact yet durable design, they withstand high-pressure conditions while offering energy-efficient operation. Ideal for construction, agriculture, and heavy machinery, they enhance system reliability and longevity.

Product Features

• High-pressure variable displacement pumps for closed-circuit operation deliver outstanding performance in demanding applications.
• Designed for industrial, construction, and mobile machinery, they offer smooth operation, high performance, and high durability.
• Their compact design ensures easy integration into various hydraulic systems.
• The advanced engineering behind these pumps enhances system responsiveness, ensuring reliable performance under heavy loads.

Product INTRODUCTION

Designed for high-performance closed-circuit systems, these variable displacement pumps provide efficient and precise hydraulic power. Their high-pressure capacity, compact design, and durability make them suitable for industrial, construction, and mobile machinery applications. Engineered for reliability, these pumps ensure smooth and responsive system operation.

PRODUCT SPECIFICATIONS

Rated displacement			30	50	70	90	110	130
	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
	Maximum output torque	Nm	227	353	480	606	749	885
Power	Continuous Power	KW	41	72	98	128	137	162
	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

Read More

Download FIle

PDF

Download FIle

HPV30(50)

PDF

HPV70(90)

PDF

HPV110(130)

PDF

detail displaY

Closed Circuit Pump

Variable Displacement Pumps

High Pressure Hydraulic Pumps

Closed Circuit Hydraulic System

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To protect the goods, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.
