Closed loop hydraulic pump/hydraulic motor manufacturer & hydraulic solutions provider - Highland Hydraulic

Axial Piston Pump Price Cast Iron - - Highland Hydraulic 1

Axial Piston Pump Price Cast Iron - - Highland Hydraulic 2

Axial Piston Pump Price Cast Iron - - Highland Hydraulic 3

Axial Piston Pump Price Cast Iron - - Highland Hydraulic 4

Axial Piston Pump Price Cast Iron - - Highland Hydraulic 5

Axial Piston Pump Price Cast Iron - - Highland Hydraulic 6

Axial Piston Pump Price Cast Iron - - Highland Hydraulic

Delivery Time:

30-60 work days

Inquiry

Application

Agricultural machinery,Walking machinery

Type

Axial piston pump

Brand

HIGHLAND

Material

Cast Iron

Product details of the axial piston pump price

Product Specification

Type: Axial piston pump

Brand: HIGHLAND

Material: Cast Iron

Application: Agricultural machinery,Walking machinery

Quick Overview

Ceaseless innovation of our engineers and the advanced production method give Highland Hydraulic axial piston pump price unique design and fine finish. Highland Hydraulic offer axial piston pump price with chic styles which meets different needs. Taking the lead in axial piston pump price manufacture industry, Highland Hydraulic has a dominant influence in this field.

Product Description

Highland Hydraulic's axial piston pump price has superior quality. The specific details are presented in the following section.

Sugarcane Harvester Closed Circuit System

Hydraulic Piston Pump For Sale

Hydraulic piston pump with a closed circuit system is designed for sugarcane harvesters,

offering high efficiency, durability, and reliable performance in the harsh conditions of sugarcane fields.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

PRODUCT SPECIFICATIONS

Rated displacement			30	50	70	90	110	130
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
Torque	Maximum output torque	Nm	227	353	480	606	749	885
Power	Continuous Power	KW	41	72	98	128	137	162
Power	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

Download FIle

PDF

Download FIle

HPV30(50)

PDF

HPV70（90）

PDF

HPV110(130)

PDF

Product Description

HPV110 axial piston pumps are equipped with advanced pressure compensation mechanisms, offering accurate and dynamic flow adjustments under varying load conditions.** Utilizing high-performance materials and precise manufacturing techniques, these pumps effectively minimize heat generation and maximize mechanical efficiency in continuous-duty industrial applications.

Product Features

International standard interface for simple and fast installation.

Modular control valves allow flexible customization and replacement.

High-strength materials ensure excellent impact resistance of the pump body.

Fully customizable to meet specific customer requirements.

Commitment to delivering highest performance at the lowest possible cost.

Product INTRODUCTION

HPV110 hydraulic pump is engineered to meet the rigorous demands of industrial machinery. With a sophisticated variable displacement mechanism and robust slipper-piston construction, it ensures exceptional hydraulic stability, smooth output flow, and minimal internal friction losses, optimizing energy consumption and extending equipment lifespan.

detail displaY

Closed Circuit System

Harvester Hydraulic Piston Pump

Closed Circuit Hydraulic Pump

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To protect the goods, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.

Company Advantages

Shandong Highland Hydraulic Seiko Co., Ltd is a new type of company in de zhou. The main business is focused on Hydraulic pump、Hydraulic motor、Hydraulic test benches. Highland Hydraulic insists on the business philosophy of 'quality creates the brand, technology makes benefits'. We promote the enterprise spirit of 'pragmatism, progress, and innovation'. We strive to build a first-class brand and continuously provide high-quality products and services. Our company has our own professional research and development team and our own unique advantages in technology development. Highland Hydraulic has been engaged in the production of Hydraulic pump、Hydraulic motor、Hydraulic test benches for many years and has accumulated rich industry experience. Based on that, we could provide comprehensive and excellent solutions according to actual situations and the needs of different customers.
Look forward to working with you to create a better future.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
