Trusted Manufacturer PV23 Variable Hydraulic Pump for Power Transmission

PV23 Variable Hydraulic Pump for Power Transmission

PV23 Variable Hydraulic Pump Manufacturer

Trusted Manufacturer PV23 Variable Hydraulic Pump For Power Transmission

Variable Displacement Control: Highland PV23 pump features an advanced swash plate mechanism that enables precise control of flow rate, enhancing system adaptability and efficiency.
High Pressure Output: Capable of delivering high pressure under continuous operation, ideal for demanding power transmission in mobile and industrial machinery.
Long Service Life: Manufactured with premium-grade components to ensure durability, corrosion resistance, and consistent performance over time.
Compact Structure: Designed with space efficiency in mind, PV23 pump fits easily into tight equipment layouts without sacrificing power.
Low Maintenance Design: Simplified internal components reduce wear and tear, resulting in lower service frequency and reduced downtime.

MOQ:

1 set

Packaging Details:

Plywood case

Payment Terms:

T/T, Western Union

Supply Ability:

100 sets per month

Certificate:

CE ISO9001

Inquiry

Write a Review

Hydraulic Pump Mode

PV23

Application

Walking machinery

Characteristic

High efficiency

Type

Axial piston pump

Pressure

42mpa

Brand

HIGHLAND

Operation Mode

Closed Circuit Hydraulic System

Working Medium

Hydraulic Oil

Warranty

1 Year

Material

Cast Iron

Trusted Manufacturer PV23 Variable Hydraulic Pump

For Power Transmission

Highland PV23 variable hydraulic pump delivers high-efficiency, reliable performance for

power transmission applications, with adjustable displacement and durable construction.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Highland PV23 variable displacement hydraulic pump provides reliable, energy-efficient power for transmission systems. Built for durability and high pressure, it ensures smooth performance with minimal maintenance, making it ideal for mobile and industrial applications.

Product Features

Highland PV23 variable hydraulic pump is a high-performance solution for power transmission systems requiring efficiency, adaptability, and durability. Engineered by a trusted manufacturer,
Higland hydraulic pump offers variable displacement control, allowing precise hydraulic flow adjustment based on system needs.
Its high-pressure capability supports a wide range of mobile and industrial equipment, including mixer trucks and construction machinery.

Product INTRODUCTION

Highland hydraulic are a trusted manufacturer of the PV23 variable hydraulic pump, engineered for power transmission systems requiring efficient flow control and high performance. Compact, durable, and maintenance-friendly, it’s an ideal choice for demanding applications.

PRODUCT SPECIFICATIONS

Rated displacement			20	22	23	110
Rated displacement	Maximum displacement	ml/r	33.3	69.8	89	110.8
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3200	2700	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	342.6	432.9	535.3
Torque	Maximum output torque	Nm	227	480	606	749
Power	Continuous Power	KW	41	98	128	137
Power	Maximum power	KW	57	105	138	159
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	PV series hydraulic pump Hydraulic oil drainage	kg	45	63	79	79

PV20

PDF

PV22

PDF

PV23

PDF

PV110

PDF

detail displaY

PV23 Variable Hydraulic Pump

Power Transmission Hydraulic Pump

Variable Displacement Piston Pump

Product Application

6-12 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

About Us

Shandong Highland Hydraulic Seiko Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with more than 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.

Packing & Delivery

To protect hydrostatic pump, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.

What is the supply ability for the Hydraulic Piston Pumps?

The supply ability for the Hydraulic Piston Pumps is 200 Sets per month.
