Closed loop hydraulic pump/hydraulic motor manufacturer & hydraulic solutions provider - Highland Hydraulic

Tailored Hydraulic System For Agriculture And Industry Hydraulics 2

Hydraulic System For Agriculture Hydraulics

Hydraulic System For Industry Hydraulics

Tailored Hydraulic System For Agriculture And Industry Hydraulics

Custom Design: Each system is tailored to meet the specific demands of agricultural machinery and industrial equipment, ensuring perfect compatibility.
High Efficiency: Engineered to maximize energy transfer, reduce losses, and improve productivity across various hydraulic applications.
Durable Components: Built with high-strength materials to withstand high pressure, heavy loads, and harsh working conditions.
Versatile Applications: Suitable for tractors, harvesters, loaders, presses, and multiple industrial machines requiring hydraulic solutions.
Easy Maintenance: Designed for simplified servicing, reduced wear, and extended operational life.

MOQ:

1 set

Packaging Details:

Plywood case

Delivery Time:

30-60 work days

Payment Terms:

T/T, Western Union

Supply Ability:

100 sets per month

Certificate:

CE ISO9001

Inquiry

Write a Review

Product Name

Hydraulic Transmission

Application

Agricultural Machinery,Walking Machinery

Function

Power components of hydraulic system

Type

Axial piston pump,Axial piston motor

Pressure

42mpa

Brand

HIGHLAND

Operation Mode

Closed Circuit Hydraulic System

Working Medium

Hydraulic Oil

Warranty

1 Year

Material

Cast Iron

Tailored Hydraulic System For Agriculture And Industry Hydraulics

Tailored hydraulic systems for agriculture and industry, offering efficiency, durability,

and precise performance for demanding machinery applications.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Highland custom hydraulic systems built for agricultural and industrial use, ensuring smooth performance, high efficiency, and long-lasting reliability in demanding working environments.

Product Features

Highland hydraulic tailored hydraulic systems are engineered to meet the unique requirements of agriculture and industrial hydraulics.
Highland hydraulic systems provide reliable power transmission, efficient energy usage, and high durability under heavy workloads.
Designed with advanced technology and premium materials, they are suitable for a wide range of applications, including tractors, harvesters, loaders, presses, and industrial production equipment.

Product INTRODUCTION

Highland hydraulic specialize in delivering tailored hydraulic systems for agricultural machinery and industrial equipment, providing durable, efficient, and versatile solutions to optimize operations.

Tailored Hydraulic System For Agriculture And Industry Hydraulics

PRODUCT SPECIFICATIONS

Rated displacement			30	50	70	90	110	130
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
Torque	Maximum output torque	Nm	227	353	480	606	749	885
Power	Continuous Power	KW	41	72	98	128	137	162
Power	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

HPV30(50)

PDF

HPV70(90)

PDF

HPV110(130)

PDF

detail displaY

Agriculture Hydraulic System

Industry Hydraulic System

Hydraulic Pump Motor System

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To ensure the safe delivery of variable piston pump and hydraulic motor, we utilize multiple layers of protective packaging. The pump is first sealed in a durable plastic bag to prevent moisture and contamination. Next, it is securely fixed within a reinforced plywood case to prevent movement and damage during transportation, given the heavy weight of the product. Finally, the plywood case, built to standard export specifications, provides sturdy protection suitable for international shipping.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.
