Smooth Power Transmission For Heavy Duty Machines

Hydraulic Power Transmission For Heavy Duty Machines

Hydraulic Transmission For Heavy Duty Machines

Smooth Power Transmission For Heavy Duty Machines

High Efficiency: Optimized hydraulic systems deliver maximum energy transfer with minimal losses, ensuring consistent performance across all heavy duty applications.
Durable Construction: Built with high-quality materials to withstand extreme loads, pressures, and harsh operating environments, extending service life.
Precision Control: Advanced design allows for accurate control of speed, torque, and movement, enhancing operational safety and reliability.
Versatile Applications: Suitable for construction machinery, agricultural equipment, and other industrial mobile machines requiring robust power transmission.
Low Maintenance: Engineered for reduced wear and tear, easy servicing, and long intervals between maintenance, lowering operational costs.

MOQ:

1 set

Packaging Details:

Plywood case

Payment Terms:

T/T, Western Union

Supply Ability:

100 sets per month

Certificate:

CE ISO9001

Inquiry

Write a Review

Hydraulic Pump Mode

PV110

Application

Walking machinery

Characteristic

High efficiency

Type

Axial piston pump

Pressure

42mpa

Brand

HIGHLAND

Operation Mode

Closed Circuit Hydraulic System

Working Medium

Hydraulic Oil

Warranty

1 Year

Material

Cast Iron

Smooth Power Transmission For Heavy Duty Machines

Reliable hydraulic solutions for smooth power transmission in heavy duty machines,

combining efficiency, durability, and precise control for industrial and mobile equipment.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Highland high performance hydraulic systems delivering smooth power transmission for heavy duty machines, ensuring efficiency, durability, and precise control for mobile and industrial applications.

Product Features

Highland hydraulic solutions ensure smooth power transmission for heavy duty machines, including construction, agricultural, and industrial mobile equipment.
Designed with high efficiency and durability, these systems reduce energy losses, maintain precise control of speed and torque, and withstand harsh operating conditions.
Highland hydraulic solutions provide consistent performance, long service life, and optimal power delivery to maximize productivity and efficiency.

Product INTRODUCTION

Highland provide engineered hydraulic solutions for heavy duty machinery, ensuring reliable, smooth, and efficient power transmission for construction, agricultural, and industrial equipment.

Hydraulic Solutions for Heavy Duty Machines

PRODUCT SPECIFICATIONS

Rated displacement			20	22	23	110
Rated displacement	Maximum displacement	ml/r	33.3	69.8	89	110.8
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3200	2700	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	342.6	432.9	535.3
Torque	Maximum output torque	Nm	227	480	606	749
Power	Continuous Power	KW	41	98	128	137
Power	Maximum power	KW	57	105	138	159
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	PV series hydraulic pump Hydraulic oil drainage	kg	45	63	79	79

PV20

PDF

PV22

PDF

PV23

PDF

PV110

PDF

detail displaY

Hydraulic Solutions

Hydraulic Power Transmission

Heavy Duty Hydraulic Transmission

Product Application

6-12 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

About Us

Shandong Highland Hydraulic Seiko Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with more than 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.

Packing & Delivery

To protect hydrostatic pump, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.

What is the supply ability for the Hydraulic Piston Pumps?

The supply ability for the Hydraulic Piston Pumps is 200 Sets per month.
