Reliable Hydraulic Power For Hay Baler Hydraulic Systems

Reliable Hydraulic Power For Hay Baler Hydraulic Systems

1. Stable Hydraulic Power Output: Designed to deliver consistent pressure and flow, these hydraulic systems ensure smooth operation of compression, tying, and discharge functions, helping hay balers maintain uniform bale density and reliable performance.

2. Heavy-Duty Durability for Field Use: Built to withstand dust, vibration, shock loads, and continuous operation, the hydraulic components perform reliably during long baling cycles and harsh outdoor working conditions.

3. Efficient Power Transmission: Optimized internal design minimizes energy loss, improving overall system efficiency and reducing fuel consumption while maintaining strong and responsive hydraulic power throughout operation.

4. Smooth and Precise Control: Advanced hydraulic control ensures accurate motion and timing of baler mechanisms, reducing mechanical stress and improving operational stability even under varying crop conditions.

5. Low Maintenance and Extended Service Life: High-quality materials, robust sealing systems, and wear-resistant components reduce leakage and downtime, extending maintenance intervals and lowering total operating costs.

MOQ:

1 set

Packaging Details:

Plywood case

Delivery Time:

15 DAYS FOR SMALL BATCH, 60 DAYS FOR MORE THAN 100 SETS

Payment Terms:

T/T, Western Union

Supply Ability:

100 sets per month

Inquiry

Write a Review

Application

Agricultural Machinery,Walking Machinery

Characteristic

High efficiency,Smoother operation,Simple layout

Function

Hydraulic System Components

Pressure

42mpa

Brand

HIGHLAND

Operation Mode

Closed Circuit Hydraulic System

Working Medium

Hydraulic Oil

Material

Cast Iron

Reliable Hydraulic Power For Hay Baler Hydraulic Systems

Highland Reliable hydraulic power solutions for hay baler systems, offering stable performance,

efficient power transmission, and durable operation for modern agricultural baling equipment.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Highland hydraulic power solutions deliver consistent pressure and reliable flow for hay baler systems. Designed for durability and efficiency, they support smooth compression and discharge operations while reducing maintenance needs and operating costs.

Product Features

Reliable Hydraulic Power for Hay Baler Hydraulic Systems is engineered to meet the demanding requirements of modern baling equipment.
Highland hydraulic solutions provide stable pressure, consistent flow, and precise control for key baler functions such as compression, binding, and bale discharge.
Designed for continuous operation in harsh agricultural environments, Highland hydraulic systems ensure dependable performance throughout long working hours.

PRODUCT INTRODUCTION

Developed for hay baler hydraulic systems, Highland reliable hydraulic power solutions combine efficiency, durability, and stable performance. They help manufacturers and operators achieve consistent baling results under demanding agricultural conditions.

PRODUCT SPECIFICATIONS

Rated displacement			30	50	70	90	110	130
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
Torque	Maximum output torque	Nm	227	353	480	606	749	885
Power	Continuous Power	KW	41	72	98	128	137	162
Power	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

HPV30(50)

PDF

HPV70(90)

PDF

HPV110(130)

PDF

detail displaY

Hay Baler Hydraulic Systems

Reliable Hydraulic Power

Agricultural Baler Hydraulics

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To ensure the safe delivery of variable piston pump and hydraulic motor, we utilize multiple layers of protective packaging. The pump is first sealed in a durable plastic bag to prevent moisture and contamination. Next, it is securely fixed within a reinforced plywood case to prevent movement and damage during transportation, given the heavy weight of the product. Finally, the plywood case, built to standard export specifications, provides sturdy protection suitable for international shipping.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Portable hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.
