Concrete Mixer Trucks Hydraulic Piston Pumps

Premium Quality PV22 Hydraulic Piston Pump For Concrete Mixer Trucks

Premium Quality PV22 Hydraulic Piston Pump

PV22 Hydraulic Piston Pump For Concrete Mixer Trucks

Hydraulic Piston Pump For Concrete Mixer Trucks

PV22 Piston Pump For Concrete Mixer Trucks

Premium Quality PV22 Hydraulic Piston Pump For Concrete Mixer Trucks

1. High Performance: PV22 hydraulic piston pump delivers consistent high-pressure output, ensuring smooth and efficient operation of concrete mixer trucks.
2. Durable Construction: Made with high-strength materials and precision machining for extended service life in harsh working conditions.
3. Variable Displacement: Adjustable flow rates allow better control and optimized power usage for different applications.
4. Energy Efficiency: Designed to reduce energy loss, improving overall fuel efficiency of the hydraulic system.
5. Easy Maintenance: Modular design and replaceable components make servicing and parts replacement fast and cost-effective.

MOQ:

1 set

Packaging Details:

Plywood case

Payment Terms:

T/T, Western Union

Supply Ability:

100 sets per month

Certificate:

CE ISO9001

Inquiry

Write a Review

Hydraulic Pump Mode

PV22

Application

Walking machinery

Characteristic

High efficiency

Type

Axial piston pump

Pressure

42mpa

Brand

HIGHLAND

Operation Mode

Closed Circuit Hydraulic System

Working Medium

Hydraulic Oil

Warranty

1 Year

Material

Cast Iron

Premium Quality PV22 Hydraulic Piston Pump for Concrete Mixer Trucks

Premium PV22 hydraulic piston pump engineered for concrete mixer trucks,

offering high efficiency, durability, and precise control for heavy-duty construction applications.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Highland PV22 hydraulic piston pump provides reliable power for concrete mixer trucks, combining high performance, energy efficiency, and long-lasting durability. Designed for heavy-duty use, it ensures stable operation and optimal hydraulic flow, supporting efficient mixing and concrete delivery.

High Efficiency PV23 Axial Piston Pump for Hydraulic Drive

PV23 Axial Piston Pump for Hydraulic Drive

Product Features

Highland PV22 hydraulic piston pump is a high-quality solution specifically designed for concrete mixer trucks, providing exceptional performance in demanding construction environments.
Built with advanced axial piston technology, it delivers reliable hydraulic power, variable displacement control, and superior efficiency.
With factory direct pricing and proven reliability, Highland PV22 hydraulic pump is an ideal choice for manufacturers and maintenance service providers looking to optimize hydraulic systems in mobile concrete machinery.

Product INTRODUCTION

Highland PV22 hydraulic piston pump is engineered for concrete mixer truck applications, delivering powerful and consistent hydraulic pressure. Its robust design, adjustable displacement, and low-maintenance structure make it a preferred choice for OEM manufacturers and aftermarket replacements worldwide.

PRODUCT SPECIFICATIONS

Rated displacement			20	22	23	110
Rated displacement	Maximum displacement	ml/r	33.3	69.8	89	110.8
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3200	2700	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	342.6	432.9	535.3
Torque	Maximum output torque	Nm	227	480	606	749
Power	Continuous Power	KW	41	98	128	137
Power	Maximum power	KW	57	105	138	159
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	PV series hydraulic pump Hydraulic oil drainage	kg	45	63	79	79

PV20

PDF

PV22

PDF

PV23

PDF

PV110

PDF

detail displaY

PV22 Hydraulic Piston Pumps

Concrete Mixer Truck Pumps

High Pressure Hydraulic Pump For Mixers

Product Application

6-12 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

About Us

Shandong Highland Hydraulic Seiko Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with more than 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.

Packing & Delivery

To protect hydrostatic pump, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.

What is the supply ability for the Hydraulic Piston Pumps?

The supply ability for the Hydraulic Piston Pumps is 200 Sets per month.
