Variable Piston Pump PV23 Wholesale - Highland Hydraulic
Product details of the variable piston pump
Product Specification
Hydraulic Pump Mode: PV23
Application: Walking machinery
Characteristic: High efficiency
Quick Overview
Shandong Highland Hydraulic Seiko Co., Ltd takes quality of materiel seriously. Highland Hydraulic offers this product with various practical functions. The product, provided at a competitive price, is widely used in the market.
Product Introduction
Compared with other products in the same industry, Highland Hydraulic's variable piston pump has the following characteristics.
Professional Manufacturer PV23 Hydraulic Plunger Pump
our advantage
Product Description
PV23 hydraulic plunger pump is built for high-pressure applications, ensuring optimal efficiency and durability. It features advanced hydraulic technology that enhances performance while reducing energy consumption. Its stable pressure control allows for smooth operation in demanding environments, making it an essential component for heavy-duty machinery.
Product Features
- PV23 hydraulic plunger pump is a premium-quality hydraulic component engineered for superior performance and reliability.
- Designed with precision manufacturing techniques, it ensures smooth and efficient operation while maintaining high-pressure stability.
- Highland hydraulic plunger pump is widely used in construction, mining, and industrial machinery, delivering consistent fluid flow and optimal power transmission.
Product INTRODUCTION
As a leading manufacturer, Highland Hydraulic, we specialize in producing high-performance PV23 hydraulic plunger pumps. Designed for industrial and construction use, these pumps deliver consistent pressure, smooth operation, and long-lasting durability. Our advanced manufacturing techniques ensure exceptional quality, efficiency, and reliability.
PRODUCT SPECIFICATIONS
|
Rated displacement |
|
20 |
22 |
23 |
110 |
|
|
Maximum displacement |
ml/r |
33.3 |
69.8 |
89 |
110.8 |
|
|
Speed |
Maximum continuous operating speed (Full load condition) |
r/min |
3500 |
3200 |
2700 |
2700 |
|
Rated speed |
r/min |
2500 |
|
|||
|
Minimum continuous operating speed |
r/min |
500 |
|
|||
|
Pressure |
Rated working pressure |
Mpa |
35 |
|
||
|
Maximum working pressure (instantaneous) |
Mpa |
42 |
|
|||
|
Continuous working pressure ( Δ P) |
Mpa |
30 |
|
|||
|
Allowable shell pressure (absolute) |
Mpa |
Constant0.25，Peak value0.5 |
|
|||
|
Torque |
Continuous output torque (Under continuous work pressure) |
Nm |
162.3 |
342.6 |
432.9 |
535.3 |
|
Maximum output torque |
Nm |
227 |
480 |
606 |
749 |
|
|
Power |
Continuous Power |
KW |
41 |
98 |
128 |
137 |
|
Maximum power |
KW |
57 |
105 |
138 |
159 |
|
|
Temperature |
Allowable temperature of shell |
℃ |
80 |
|
||
|
Maximum operating temperature of fuel tank |
℃ |
70 |
|
|||
|
Angle |
Maximum inclination angle of the inclined plate |
° |
± 18 ° |
|
||
|
Weight |
PV series hydraulic pump Hydraulic oil drainage |
kg |
45 |
63 |
79 |
79 |
detail displaY
Product Application
About Us
Shandong Highland Hydraulic Seiko Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with more than 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.
Packing & Delivery
To protect hydrostatic pump, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.
