Variable Piston Pump HIGHLAND Wholesale - Highland Hydraulic
High Pressure HIgh efficiency hydraulic plunger pump
for harvesting machine
A durable, high efficiency hydraulic plunger pump built to enhance the performance and reliablity
of modern harvesting machines under heavy workloads.
our advantage
Product Description
Highland hydraulic plunger pump provide high-pressure, high-efficiency solutions for agricultural harvesters. Featuring variable displacement for precise control, they ensure smooth and reliable performance. Designed with durability in mind, they withstand harsh conditions, reducing downtime and maintenance needs.
Product Features
- Highland hydraulic plunger pumps are engineered to meet the rigorous demands of harvesting machines.
- Designed for high performance and efficiency, they offer smooth operation, and durability under heavy workloads.
- With advanced hydraulic technology, Highland hydraulic pumps optimize energy consumption while providing reliable power transmission, enhancing machine productivity.
Product INTRODUCTION
Highland hydraulic manufacture advanced high efficiency hydraulic plunger pumps, specifically designed for agricultural harvesting machines. With high efficiency, precise control, and robust construction, our pumps enhance performance and reliability in modern farming operations, ensuring maximum productivity and reduced energy consumption.
PRODUCT SPECIFICATIONS
|
Rated displacement |
|
30 |
50 |
70 |
90 |
110 |
130 |
|
|
Maximum displacement |
ml/r |
30 |
50 |
70 |
90 |
110 |
130 |
|
|
Speed |
Maximum continuous operating speed (Full load condition) |
r/min |
3500 |
3500 |
3200 |
3000 |
2900 |
2700 |
|
Rated speed |
r/min |
2500 |
||||||
|
Minimum continuous operating speed |
r/min |
500 |
||||||
|
Pressure |
Rated working pressure |
Mpa |
35 |
|||||
|
Maximum working pressure (instantaneous) |
Mpa |
42 |
||||||
|
Continuous working pressure ( Δ P) |
Mpa |
30 |
||||||
|
Allowable shell pressure (absolute) |
Mpa |
Constant0.25，Peak value0.5 |
||||||
|
Torque |
Continuous output torque (Under continuous work pressure) |
Nm |
162.3 |
252.3 |
342.6 |
432.9 |
535.3 |
632.4 |
|
Maximum output torque |
Nm |
227 |
353 |
480 |
606 |
749 |
885 |
|
|
Power |
Continuous Power |
KW |
41 |
72 |
98 |
128 |
137 |
162 |
|
Maximum power |
KW |
57 |
87 |
105 |
138 |
159 |
188 |
|
|
Temperature |
Allowable temperature of shell |
℃ |
80 |
|||||
|
Maximum operating temperature of fuel tank |
℃ |
70 |
||||||
|
Angle |
Maximum inclination angle of the inclined plate |
° |
± 18 ° |
|||||
|
Weight |
HPV series hydraulic pump Hydraulic oil drainage |
kg |
45 |
46 |
63 |
64 |
87 |
87.5 |
detail displaY
Product Application
Packing & Delivery
To ensure the safe delivery of variable piston pump and hydraulic motor, we utilize multiple layers of protective packaging. The pump is first sealed in a durable plastic bag to prevent moisture and contamination. Next, it is securely fixed within a reinforced plywood case to prevent movement and damage during transportation, given the heavy weight of the product. Finally, the plywood case, built to standard export specifications, provides sturdy protection suitable for international shipping.
FAQ
Company Advantages
· With the latest technology, Highland Hydraulic variable piston pump can be done quickly in a high degree of precision.
· This product undergoes in-house quality assurance procedures conducted by our QC team.
· The offered product is highly demanded among customers for its outstanding features.
Company Features
· Highland Hydraulic has always been staying at the top in variable piston pump market.
· Shandong Highland Hydraulic Seiko Co., Ltd has attracted and nurtured a large number of senior technical management elites in variable piston pump industry.
· Promoting the improvement of variable piston pump for the work is the goal for Highland Hydraulic. Call!
Application of the Product
variable piston pump of Highland Hydraulic is widely used and has a wide range of applications.
With rich manufacturing experience and strong production strength, Highland Hydraulic is able to provide professional solutions according to customers' actual needs.
