Closed loop hydraulic pump/hydraulic motor manufacturer & hydraulic solutions provider - Highland Hydraulic

Hydrostatic Pumps and Motors HIGHLAND Wholesale - Highland Hydraulic 1

Hydrostatic Pumps and Motors HIGHLAND Wholesale - Highland Hydraulic 2

Hydrostatic Pumps and Motors HIGHLAND Wholesale - Highland Hydraulic 3

Hydrostatic Pumps and Motors HIGHLAND Wholesale - Highland Hydraulic 4

Hydrostatic Pumps and Motors HIGHLAND Wholesale - Highland Hydraulic 5

Hydrostatic Pumps and Motors HIGHLAND Wholesale - Highland Hydraulic 6

Hydrostatic Pumps and Motors HIGHLAND Wholesale - Highland Hydraulic 7

Hydrostatic Pumps and Motors HIGHLAND Wholesale - Highland Hydraulic

Certificate:

CE ISO9001

Inquiry

Application

Walking machinery

Type

Axial piston pump

Brand

HIGHLAND

Working Medium

Hydraulic Oil

Product details of the hydrostatic pumps and motors

Product Specification

Application: Walking machinery

Type: Axial piston pump

Working Medium: Hydraulic Oil

Brand: HIGHLAND

Product Introduction

Highland Hydraulic hydrostatic pumps and motors is manufactured using top-class materials and advanced tools and equipment. The performance of the product is assessed by third-party professional testing. Shandong Highland Hydraulic Seiko Co., Ltd has complete sales networks and stable cooperation partners all over the world.

Factory Direct Supply Axial Piston Pump PV110 Manufacturer

PV110 Axial Piston Pump delivers high efficiency, durability, and precise control.

With robust construction and smooth operation, it ensures reliable performance in industrial and mobile hydraulic systems.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

PV110 Axial Piston Pump is engineered for superior hydraulic performance. It offers high-pressure operation, excellent volumetric efficiency, and smooth power delivery. With a compact and rugged design, it ensures durability and reliable functionality across various industries. The pump is optimized for reduced energy consumption, minimal noise, and maximum efficiency, making it a preferred choice for industrial and mobile hydraulic systems.

Product Features

PV110 Axial Piston Pump is a high-quality hydraulic pump built for demanding applications.
Designed with advanced axial piston technology, it offers exceptional efficiency, high pressure capability.
Its compact and durable design ensures optimal performance in industrial, construction, and agricultural machinery.
Manufactured with strict quality control standards, PV110 piston pump guarantees superior performance, minimal maintenance, and enhanced operational stability.

Product INTRODUCTION

Designed for high efficiency and durability, PV110 Axial Piston Pump is a factory-direct solution for hydraulic applications. Its advanced axial piston technology ensures smooth operation, high pressure handling, and excellent reliability. Suitable for construction, agriculture, and industrial uses, it provides precise flow control and energy-efficient performance, reducing operational costs while maximizing productivity.

PV110 Variable Displacement Piston Pumps

PRODUCT SPECIFICATIONS

Rated displacement			20	22	23	110
Rated displacement	Maximum displacement	ml/r	33.3	69.8	89	110.8
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3200	2700	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	342.6	432.9	535.3
Torque	Maximum output torque	Nm	227	480	606	749
Power	Continuous Power	KW	41	98	128	137
Power	Maximum power	KW	57	105	138	159
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	PV series hydraulic pump Hydraulic oil drainage	kg	45	63	79	79

Button

PV20

PDF

PV22

PDF

PV23

PDF

PV110

PDF

detail displaY

Axial Piston Pump

Piston Pump PV110

PV110 Axial Piston Pumps

Axial Piston Pump Manufacturer

Product Application

6-12 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

About Us

Shandong Highland Hydraulic Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with nearly 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.

Packing & Delivery

To protect hydrostatic pump, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.

What is the supply ability for the Hydraulic Piston Pumps?

The supply ability for the Hydraulic Piston Pumps is 200 Sets per month.

Company Advantage

• Our company enjoys great geographic location with different main transportation lines crossing the city. Besides, the unimpeded road condition provides strong guarantee for the successful transportation of products.
• Highland Hydraulic has established many good cooperative relationships through long-term and multiple cooperation with excellent enterprises in the field. It has laid a solid foundation for our stable development.
• Highland Hydraulic has been exploring and innovating for years. And now we have grown into a modern company with rich production experience and mature processing technique.
Discounts will be offered on your first purchase for Highland Hydraulic's Hydraulic pump、Hydraulic motor、Hydraulic test benches.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
