Closed loop hydraulic pump/hydraulic motor manufacturer & hydraulic solutions provider - Highland Hydraulic

Hydrostatic Pump Manufacturers Western Union by Highland Hydraulic 1

Hydrostatic Pump Manufacturers Western Union by Highland Hydraulic 2

Hydrostatic Pump Manufacturers Western Union by Highland Hydraulic 3

Hydrostatic Pump Manufacturers Western Union by Highland Hydraulic 4

Hydrostatic Pump Manufacturers Western Union by Highland Hydraulic

Payment Terms:

T/T, Western Union

Inquiry

more products

Hydrostatic Pump

Hydrostatic Motor

Hydraulic Test Bench

Portable Hydraulic Tester

Send your inquiry

Pressure

42mpa

Brand

HIGHLAND

Operation Mode

Closed Circuit Hydraulic System

Material

Cast Iron

Product details of the hydrostatic pump manufacturers

Product Specification

Material: Cast Iron

Operation Mode: Closed Circuit Hydraulic System

Brand: HIGHLAND

Pressure: 42mpa

Product Information

Highland Hydraulic's collection combines craftsmanship with advanced technology. The product has been recognized internationally for its performance and quality. Shandong Highland Hydraulic Seiko Co., Ltd will provide comprehensive suggestions and guide to customers about our hydrostatic pump manufacturers.

LPV Series Hydrostatic Pump For Construction Machinery

Variable displacement hydraulic pump for closed loop operation

PRODUCT SPECIFICATIONS

Rated displacement			30	50	70	90	110	130
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
Torque	Maximum output torque	Nm	227	353	480	606	749	885
Power	Continuous Power	KW	41	72	98	128	137	162
Power	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

Download FIle

PDF

Download FIle

HPV30(50)

PDF

HPV70(90)

PDF

HPV110(130)

PDF

Products Advantages

HPV series closed axial piston pump offers high efficiency, compact design, and long service life, making it the ideal choice for reliable hydraulic systems.

Hydrostatic Pump Manufacturers Western Union by Highland Hydraulic 11

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Hydrostatic Pump Manufacturers Western Union by Highland Hydraulic 12

Low price

We promise the lowest price for new products of the same variety in the world

Hydrostatic Pump Manufacturers Western Union by Highland Hydraulic 13

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Application

The LPV series closed axial piston pump is ideal for applications requiring a reliable and efficient hydraulic power source. Whether it's for industrial machinery, construction equipment, or agricultural vehicles, this pump delivers outstanding performance in demanding environments.

6-20 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground LHD

mining loader

Curb Stone Forming Machine

Harvester

Forage Silage Harvester

Cane Grabber Machine

LV90 Closed Axial Piston Pump - Compact Design

Product Description

Designed for challenging industrial environments,HPV110 pump integrates precise axial piston displacement technology. Its optimized rotating group and reinforced bearing arrangement reduce internal leakage and vibration, providing smooth, stable fluid delivery while significantly enhancing overall hydraulic system performance.

Product Details

Its closed axial piston design, it provides reliable performance and long service life. Its compact size makes it ideal for installations where space is limited.

Electric Propprtional servo control

Hydraulic servo control

1727143443469

Features

Simplified structure allows easy dismantling, significantly reducing maintenance costs.

Versatile control options: manual, electric, and hydraulic modes easily switchable.

Superior pump body design capable of handling extreme operational conditions.

International standard interfaces ensure excellent compatibility and universality.

Flexible customization options tailored to customer-specific needs.

Product Application

LPV70 Closed Axial Piston Pump is designed for compact spaces and operates efficiently. It is ideal for use in hydraulic systems requiring high pressure and minimal noise output. This pump is suitable for various industrial applications, such as agriculture machinery.

Harvesting machine

Self-propelled mowers

Grape harvester

About Us

Shandong Highland Hydraulic Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with nearly 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.

Packing & Delivery

To protect the goods, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

FAQ

Tell us about your project requirements and we will figure out a solution that will meet your budget and design expectations.

What are the typical applications for the HPV110 Closed Axial Piston Pump?

The HPV110 Closed Axial Piston Pump is commonly used in industrial and mobile hydraulic systems, including construction equipment, agricultural machinery, and material handling equipment.

What makes the HPV110 Closed Axial Piston Pump compact?

The compact design of the LPV70 Closed Axial Piston Pump allows for easy installation in tight spaces and provides greater flexibility in equipment design and layout.

Can the HPV110 Closed Axial Piston Pump handle high pressure applications?

Yes, the HPV110 Closed Axial Piston Pump is designed to handle high pressure applications, making it suitable for demanding hydraulic systems.

What kind of hydraulic fluid is recommended for use with the LPV90 Closed Axial Piston Pump?

The HPV110 Closed Axial Piston Pump is compatible with a variety of hydraulic fluids, but it is recommended to use fluids that meet the manufacturer's specifications for optimal performance.

Can the HPV110 Closed Axial Piston Pump be used in harsh environmental conditions?

Yes, the HPV110 Closed Axial Piston Pump is designed to withstand harsh environmental conditions, including extreme temperatures, high humidity, and exposure to dust and debris.

How can I ensure proper maintenance of the HPV110 Closed Axial Piston Pump?

Proper maintenance of the HPV110 Closed Axial Piston Pump includes regular inspection, checking for leaks, monitoring fluid levels, and following the manufacturer's recommended maintenance schedule.

Company Advantage

• In order to promptly solve customers' difficulties and doubts, we provide information inquiry service and other related services, according to our advantageous resources and customers' needs.
• Our company has obvious geographical location advantages, so the transportation is very convenient.
• Our company respects and cultivates talents, so as to fulfill their potential. Based on the complete personnel management system, we have formed a talents team with both ability and virtue.
• The main brand of our company has become a favorite in the market, which is not only widely praised in the domestic market, but also has been favored by consumers in the international market.
Leave your contact information and you can get more details about Hydraulic pump、Hydraulic motor、Hydraulic test benches.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
