Hydrostatic Pump Manufacturers PV110 - - Highland Hydraulic

Product details of the hydrostatic pump manufacturers

Product Specification

Brand: HIGHLAND

Hydraulic Pump Mode: PV110

Operation Mode: Closed Circuit Hydraulic System

Pressure: 42mpa

Characteristic: High efficiency

Quick Detail

The costs for Highland Hydraulic hydrostatic pump manufacturers is reduced in the design phase. hydrostatic pump manufacturers can be easily adjustable to custom-made products. Highland Hydraulic's hydrostatic pump manufacturers is widely used in the industry and is widely recognized by customers. We own professional and complete quality assurance for our each hydrostatic pump manufacturers.

Product Description

With a focus on details, Highland Hydraulic strives to create high-quality hydrostatic pump manufacturers.

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Highland variable displacement hydraulic piston pumps are engineered for maximum efficiency and adaptability. They offer smooth and precise control, ensuring optimal performance in diverse industrial applications. Designed with advanced materials and technology, our pumps reduce energy consumption while maintaining durability.

Product Features

• As a leading manufacturer of high-efficiency variable displacement hydraulic piston pumps, we provide cutting-edge solutions for industrial and mobile hydraulic systems.
• Highland hydraulic pumps feature enhanced efficiency, and durability, making them ideal for applications in construction, agriculture, manufacturing, and more.
• We continuously invest in R&D to develop advanced hydraulic technologies, ensuring reliability and longevity in demanding conditions.

Product INTRODUCTION

Highland hydraulic manufacture high-performance variable displacement hydraulic piston pumps, designed to deliver efficiency, durability, and precise control. Highland hydraulic pumps support various industries, including construction, agriculture, and manufacturing, ensuring superior hydraulic performance with energy-saving benefits.

PRODUCT SPECIFICATIONS

Rated displacement			20	22	23	110
	Maximum displacement	ml/r	33.3	69.8	89	110.8
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3200	2700	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	342.6	432.9	535.3
	Maximum output torque	Nm	227	480	606	749
Power	Continuous Power	KW	41	98	128	137
	Maximum power	KW	57	105	138	159
Temperature	Allowable temperature of shell	℃	80
	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	PV series hydraulic pump Hydraulic oil drainage	kg	45	63	79	79

Read More

PV20

PDF

PV22

PDF

PV23

PDF

PV110

PDF

detail displaY

Hydraulic Piston Pump

Variable Displacement Piston Pump

Variable Piston Pump Manufacturer

Product Application

6-12 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

About Us

Shandong Highland Hydraulic Seiko Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with more than 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.

Packing & Delivery

To protect hydrostatic pump, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

Company Introduction

Shandong Highland Hydraulic Seiko Co., Ltd is a comprehensive enterprise with diverse business range. We are engaged in the production, sales and trade and Hydraulic pump、Hydraulic motor、Hydraulic test benches are key products. During the process of development, our company adopts advanced management concept in accordance with standards, science and large-scale. Besides, we use effective modern management methods to continuously pursue excellence and innovation, so as to create competitive advantages for our company. Highland Hydraulic has a group of senior talents in the industry, who have the professional and dedicated working spirit. According to different needs of customers, we could customize comprehensive and efficient solutions for them.
Welcome all customers to come for cooperation.
