Hydrostatic Pump Manufacturers Closed Circuit Hydraulic System by Highland Hydraulic
Product details of the hydrostatic pump manufacturers
Product Specification
Pressure: 42mpa
Working Medium: Hydraulic Oil
Displacement: 90ml/r
Operation Mode: Closed Circuit Hydraulic System
Quick Overview
Highland Hydraulic hydrostatic pump manufacturers is manufactured exactly according to your specifications by using the most advanced technology and equipment. The product is thoroughly inspected by our quality inspectors as per the set quality guidelines. With time going on, our advantage for large capacity can be fully showed in on-time delivery for Shandong Highland Hydraulic Seiko Co., Ltd.
Product Introduction
With a focus on every detail of hydrostatic pump manufacturers, we strive to create high-quality products.
LPV Series Hydrostatic Pump For Construction Machinery
Variable displacement hydraulic pump for closed loop operation
Products Advantages
LPV series closed axial piston pump offers high efficiency, compact design, and long service life, making it the ideal choice for reliable hydraulic systems.
Product Application
The LPV series closed axial piston pump is ideal for applications requiring a reliable and efficient hydraulic power source. Whether it's for industrial machinery, construction equipment, or agricultural vehicles, this pump delivers outstanding performance in demanding environments.
LV70 Closed Axial Piston Pump - Compact Design
Product Description
With its compact form factor, the LPV70 integrates effortlessly into space-constrained installations. The pump's streamlined, easily accessible construction simplifies maintenance, enhances reliability, and reduces potential leak points, contributing to overall system longevity.
Product Specifications
|
Rated displacement |
|
30 |
50 |
70 |
90 |
110 |
130 |
160 |
180 |
200 |
|
|
Maximum displacement |
ml/r |
30 |
50 |
70 |
90 |
110 |
130 |
160 |
180 |
200 |
|
|
Speed |
Maximum continuous operating speed (Full load condition) |
r/min |
3500 |
3500 |
3200 |
3000 |
2900 |
2700 |
2400 |
2400 |
2400 |
|
Rated speed |
r/min |
2500 |
2200 |
||||||||
|
Minimum continuous operating speed |
r/min |
500 |
|||||||||
|
Pressure |
Rated working pressure |
Mpa |
35 |
||||||||
|
Maximum working pressure (instantaneous) |
Mpa |
42 |
|||||||||
|
Continuous working pressure ( Δ P) |
Mpa |
30 |
|||||||||
|
Allowable shell pressure (absolute) |
Mpa |
Constant0.25，Peak value0.5 |
|||||||||
|
Torque |
Continuous output torque (Under continuous work pressure) |
Nm |
162.3 |
252.3 |
342.6 |
432.9 |
535.3 |
632.4 |
776 |
875 |
972 |
|
Maximum output torque |
Nm |
227 |
353 |
480 |
606 |
749 |
885 |
1000 |
1098 |
1200 |
|
|
Power |
Continuous Power |
KW |
41 |
72 |
98 |
128 |
137 |
162 |
191 |
224 |
279 |
|
Maximum power |
KW |
57 |
87 |
105 |
138 |
159 |
188 |
292 |
307 |
318 |
|
|
Temperature |
Allowable temperature of shell |
℃ |
80 |
||||||||
|
Maximum operating temperature of fuel tank |
℃ |
70 |
|||||||||
|
Angle |
Maximum inclination angle of the inclined plate |
° |
± 18 ° |
||||||||
|
Weight |
LPV series hydraulic pump Hydraulic oil drainage |
kg |
44 |
45 |
62.5 |
63.5 |
71 |
96 |
98 |
140 |
144 |
Product Details
Its closed axial piston design, it provides reliable performance and long service life. Its compact size makes it ideal for installations where space is limited.
MATERIAL INTRODUCTION
LPV70 Axial Piston Pump features advanced swash plate design, providing superior volumetric efficiency and reduced energy consumption. Engineered for demanding heavy-duty machinery, it ensures reliable operation and optimal performance in harsh construction and mining environments.
Product Application
LPV70 Closed Axial Piston Pump is designed for compact spaces and operates efficiently. It is ideal for use in hydraulic systems requiring high pressure and minimal noise output. This pump is suitable for various industrial applications, such as agriculture machinery.
About Us
Shandong Highland Hydraulic Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with nearly 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.
Packing & Delivery
To protect the goods, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.
FAQ
Tell us about your project requirements and we will figure out a solution that will meet your budget and design expectations.
Company Introduction
As a modern enterprise, Shandong Highland Hydraulic Seiko Co., Ltd has a combined business mode in R&D, production, trade and service. Our main product is Hydraulic pump、Hydraulic motor、Hydraulic test benches. With the vision to become a company with the most core competitiveness in China, Highland Hydraulic has always been adhering to the development philosophy of 'honesty and credit, professionalism, concentration, and sci-tech innovation', and the core values of 'unity, cooperation, mutual benefit and win-win'. We try hard to complete the corporate mission of 'winning customers with quality and connecting the world with technology'. According to the modern enterprise management system, Highland Hydraulic established an elite team with rich industry experience in production, processing, and sales. Highland Hydraulic is able to meet customers' needs to the greatest extent by providing customers with one-stop and high-quality solutions.
If you are in need for products of reliable quality and affordable price, please contact us at any time!
