Hydrostatic Pump HPV30|HPV50|HPV70|HPV90|HPV110|HPV130 by Highland Hydraulic

Product details of the hydrostatic pump

Product Specification

Product Name: Variable Hydraulic Pump

Application: Harvesting machinery

Mode: HPV30|HPV50|HPV70|HPV90|HPV110|HPV130

Product Overview

Highland Hydraulic hydrostatic pump is manufactured with high-quality raw materials which are strictly selected from suppliers. Its quality can be guaranteed through fully mature quality test. The hydrostatic pump produced by Highland Hydraulic is widely used in industry. It is mature sales network that Highland Hydraulic has been more famous than before at home and abroad.

Product Information

Highland Hydraulic will show you the specific details of products below.

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Highland hydraulic plunger pump provide high-pressure, high-efficiency solutions for agricultural harvesters. Featuring variable displacement for precise control, they ensure smooth and reliable performance. Designed with durability in mind, they withstand harsh conditions, reducing downtime and maintenance needs.

Product Features

• Highland hydraulic plunger pumps are engineered to meet the rigorous demands of harvesting machines.
• Designed for high performance and efficiency, they offer smooth operation, and durability under heavy workloads.
• With advanced hydraulic technology, Highland hydraulic pumps optimize energy consumption while providing reliable power transmission, enhancing machine productivity.

Product INTRODUCTION

Highland hydraulic manufacture advanced high efficiency hydraulic plunger pumps, specifically designed for agricultural harvesting machines. With high efficiency, precise control, and robust construction, our pumps enhance performance and reliability in modern farming operations, ensuring maximum productivity and reduced energy consumption.

PRODUCT SPECIFICATIONS

Rated displacement			30	50	70	90	110	130
	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
	Maximum output torque	Nm	227	353	480	606	749	885
Power	Continuous Power	KW	41	72	98	128	137	162
	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

Read More

HPV30(50)

PDF

HPV70(90)

PDF

HPV110(130)

PDF

detail displaY

Hydraulic Plunger Pump

High Pressure Hydraulic Plunger Pump

Harvesting Hydraulic Plunger Pump

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To ensure the safe delivery of variable piston pump and hydraulic motor, we utilize multiple layers of protective packaging. The pump is first sealed in a durable plastic bag to prevent moisture and contamination. Next, it is securely fixed within a reinforced plywood case to prevent movement and damage during transportation, given the heavy weight of the product. Finally, the plywood case, built to standard export specifications, provides sturdy protection suitable for international shipping.

Company Introduction

Since establishment, Shandong Highland Hydraulic Seiko Co., Ltd has been an active role in the design and production of hydrostatic pump. We are widely accepted in the industry. We have brought together professional manufacturing team leaders. They have the ability to supervise all aspects of the manufacturing line and monitor progress and time frames for orders. Shandong Highland Hydraulic Seiko Co., Ltd' purpose is to strengthen its technological power to be an expert in hydrostatic pump field. Get info!
We always insist on the production of high-quality products. Welcome customers with needs to negotiate with us!
