Hydrostatic Pump CE ISO9001 by Highland Hydraulic

Company Advantages

· Our hydrostatic pump are in various style, including hydrostatic pump.

· The product performs its functions properly during the service life.

· Shandong Highland Hydraulic Seiko Co., Ltd will offer clear and detailed video guidance to customers for our hydrostatic pump.

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Built for high-pressure applications, this piston pump delivers excellent hydraulic efficiency and durability. Designed for mobile hydraulics, it provides smooth power transmission, low noise, and superior volumetric efficiency. Its rugged construction ensures reliable operation in harsh environments, making it ideal for construction, agriculture, and industrial applications.

Product Features

• Built for high-pressure applications, piston pump delivers excellent hydraulic efficiency and durability.
• Designed for mobile hydraulics, it provides smooth power transmission, low noise, and superior volumetric efficiency.
• Its rugged construction ensures reliable operation in harsh environments, making it ideal for construction, agriculture, and industrial applications.

Product INTRODUCTION

High pressure piston pump is designed for superior performance in mobile hydraulic applications. Engineered with precision, it delivers high efficiency, smooth operation, and excellent pressure capabilities. Manufactured in China under strict quality control, it ensures durability and reliability in construction, agriculture, and industrial machinery. Its compact design and energy-efficient performance make it an ideal choice for demanding hydraulic systems.

Product specification

Rated displacement			30	50	70	90	110	130
	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
	Maximum output torque	Nm	227	353	480	606	749	885
power	Continuous Power	KW	41	72	98	128	137	162
	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

HPV30(50)

PDF

HPV70(90)

PDF

HPV110(130)

PDF

detail displaY

Mobile Hydraulics

High Pressure Piston Pump

Mobile Hydraulic Piston Pump

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To ensure the safe delivery of the HPV110 variable piston pump, we utilize multiple layers of protective packaging. The pump is first sealed in a durable plastic bag to prevent moisture and contamination. Next, it is securely fixed within a reinforced plywood case to prevent movement and damage during transportation, given the heavy weight of the product. Finally, the plywood case, built to standard export specifications, provides sturdy protection suitable for international shipping.

Company Features

· Highland Hydraulic has high celebrity among customers for its fabulous hydrostatic pump.

· There are many authoritative awards for Shandong Highland Hydraulic Seiko Co., Ltd's technology.

· Highland Hydraulic strives to become the excellent provider of the hydrostatic pump solutions. Inquire online!

Product Comparison

Compared with other similar products in the market, Highland Hydraulic's hydrostatic pump is provided with the following outstanding advantages.

Enterprise Advantages

Our company has a group of highly educated, high-quality and high-level talents. They are the internal motivation for our sustainable development.

Our company insists on the service concept of 'customer first' and can supply customers with stable and high-quality services.

Highland Hydraulic implements the five development concepts of 'innovation, coordination, green, openness and sharing' and effectively combine industry development and ecological construction. Based on this, we play a demonstration role in safeguarding national ecological security.

After years' advancement, Highland Hydraulic has realized the modernization and standardization of the industry. We have also found out a sustainable development path, under the circular economy model of combining production and marketing.

Our product sales network covers all parts of the country, and some products are exported to some countries and regions in Asia, Europe, Latin America and Africa. So our company's social influence has been greatly improved.
