Product Name

Variable Hydraulic Pump

Dimension(L*W*H)

53*34*43cm

Operation Mode

Closed Circuit Hydraulic System

Product details of the hydrostatic pump

Product Specification

Dimension(L*W*H): 53*34*43cm

Operation Mode: Closed Circuit Hydraulic System

Product Name: Variable Hydraulic Pump

Product Information

Highland Hydraulic hydrostatic pump reflects the perfect blend of latest technology and innovative design. The complete quality control system makes sure that this product is of high quality. As long as other outer packing request from our customers is reasonable, Shandong Highland Hydraulic Seiko Co., Ltd will be willing to have a try.

China Manufacturer High Pressure Piston Pump

For Mobile Hydraulics

A high-pressure piston pump engineered for mobile hydraulics, ensuring efficiency,

durability, and smooth operation. Ideal for construction, agriculture, and

industrial applications with reliable performance.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Built for high-pressure applications, this piston pump delivers excellent hydraulic efficiency and durability. Designed for mobile hydraulics, it provides smooth power transmission, low noise, and superior volumetric efficiency. Its rugged construction ensures reliable operation in harsh environments, making it ideal for construction, agriculture, and industrial applications.

Product Features

Built for high-pressure applications, piston pump delivers excellent hydraulic efficiency and durability.
Designed for mobile hydraulics, it provides smooth power transmission, low noise, and superior volumetric efficiency.
Its rugged construction ensures reliable operation in harsh environments, making it ideal for construction, agriculture, and industrial applications.

Product INTRODUCTION

High pressure piston pump is designed for superior performance in mobile hydraulic applications. Engineered with precision, it delivers high efficiency, smooth operation, and excellent pressure capabilities. Manufactured in China under strict quality control, it ensures durability and reliability in construction, agriculture, and industrial machinery. Its compact design and energy-efficient performance make it an ideal choice for demanding hydraulic systems.

Product specification

Rated displacement			30	50	70	90	110	130
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
Torque	Maximum output torque	Nm	227	353	480	606	749	885
power	Continuous Power	KW	41	72	98	128	137	162
power	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

HPV30(50)

PDF

HPV70(90)

PDF

HPV110(130)

PDF

detail displaY

Mobile Hydraulics

High Pressure Piston Pump

Mobile Hydraulic Piston Pump

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To ensure the safe delivery of the HPV110 variable piston pump, we utilize multiple layers of protective packaging. The pump is first sealed in a durable plastic bag to prevent moisture and contamination. Next, it is securely fixed within a reinforced plywood case to prevent movement and damage during transportation, given the heavy weight of the product. Finally, the plywood case, built to standard export specifications, provides sturdy protection suitable for international shipping.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.
