Characteristic

High efficiency

Pressure

42mpa

Brand

HIGHLAND

Working Medium

Hydraulic Oil

Company Advantages

· The different materials are designed by Shandong Highland Hydraulic Seiko Co., Ltd to create a rich variety of hydraulic pump swash plate.

· The product has stable and reliable performance and thus can be used for a long time.

· Shandong Highland Hydraulic Seiko Co., Ltd provides a strong price advantage.

Professional Manufacturer PV23 Hydraulic Plunger Pump

PV23 hydraulic plunger pump is a high-performance solution for industrial, construction and agricultural machinery.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

PV23 hydraulic plunger pump is built for high-pressure applications, ensuring optimal efficiency and durability. It features advanced hydraulic technology that enhances performance while reducing energy consumption. Its stable pressure control allows for smooth operation in demanding environments, making it an essential component for heavy-duty machinery.

Product Features

PV23 hydraulic plunger pump is a premium-quality hydraulic component engineered for superior performance and reliability.
Designed with precision manufacturing techniques, it ensures smooth and efficient operation while maintaining high-pressure stability.
Highland hydraulic plunger pump is widely used in construction, mining, and industrial machinery, delivering consistent fluid flow and optimal power transmission.

Product INTRODUCTION

As a leading manufacturer, Highland Hydraulic, we specialize in producing high-performance PV23 hydraulic plunger pumps. Designed for industrial and construction use, these pumps deliver consistent pressure, smooth operation, and long-lasting durability. Our advanced manufacturing techniques ensure exceptional quality, efficiency, and reliability.

PRODUCT SPECIFICATIONS

Rated displacement			20	22	23	110
Rated displacement	Maximum displacement	ml/r	33.3	69.8	89	110.8
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3200	2700	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	342.6	432.9	535.3
Torque	Maximum output torque	Nm	227	480	606	749
Power	Continuous Power	KW	41	98	128	137
Power	Maximum power	KW	57	105	138	159
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	PV series hydraulic pump Hydraulic oil drainage	kg	45	63	79	79

PV20

PDF

PV22

PDF

PV23

PDF

PV110

PDF

detail displaY

Hydraulic Plunger Pump

Pv23 Hydraulic Plunger Pump

Hydraulic Plunger Pump Manufacturer

Product Application

6-12 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

About Us

Shandong Highland Hydraulic Seiko Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with more than 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.

Packing & Delivery

To protect hydrostatic pump, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.

What is the supply ability for the Hydraulic Piston Pumps?

The supply ability for the Hydraulic Piston Pumps is 200 Sets per month.

Company Features

· As a manufacturer of hydraulic pump swash plate, Shandong Highland Hydraulic Seiko Co., Ltd has many years of experience to help customers reach product dreams.

· Our strong technical capabilities can accelerate the production of large quantities of output hydraulic pump swash plate.

· Highland Hydraulic is a company who is responsible for customer satisfication. Get price!

Product Details

The following is the section for presenting details of the hydraulic pump swash plate.

Application of the Product

hydraulic pump swash plate developed and produced by our company can be widely used in various industries and professional fields.

Highland Hydraulic could customize comprehensive and efficient solutions according to customers' different needs.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
