Hydraulic Pump Swash Plate HIGHLAND Wholesale - Highland Hydraulic
Company Advantages
· The raw materials of Highland Hydraulic hydraulic pump swash plate are well prepared and are efficiently used in the production.
· The products have passed strict quality examination and inspection before they leave the factory.
· Shandong Highland Hydraulic Seiko Co., Ltd has professionalized its service system to benefit the customer with convenience.
LPV Series Hydrostatic Pump For Construction Machinery
Variable displacement hydraulic pump for closed loop operation
PRODUCT SPECIFICATIONS
|
Rated displacement |
|
30 |
50 |
70 |
90 |
110 |
130 |
|
|
Maximum displacement |
ml/r |
30 |
50 |
70 |
90 |
110 |
130 |
|
|
Speed |
Maximum continuous operating speed (Full load condition) |
r/min |
3500 |
3500 |
3200 |
3000 |
2900 |
2700 |
|
Rated speed |
r/min |
2500 |
||||||
|
Minimum continuous operating speed |
r/min |
500 |
||||||
|
Pressure |
Rated working pressure |
Mpa |
35 |
|||||
|
Maximum working pressure (instantaneous) |
Mpa |
42 |
||||||
|
Continuous working pressure ( Δ P) |
Mpa |
30 |
||||||
|
Allowable shell pressure (absolute) |
Mpa |
Constant0.25，Peak value0.5 |
||||||
|
Torque |
Continuous output torque (Under continuous work pressure) |
Nm |
162.3 |
252.3 |
342.6 |
432.9 |
535.3 |
632.4 |
|
Maximum output torque |
Nm |
227 |
353 |
480 |
606 |
749 |
885 |
|
|
Power |
Continuous Power |
KW |
41 |
72 |
98 |
128 |
137 |
162 |
|
Maximum power |
KW |
57 |
87 |
105 |
138 |
159 |
188 |
|
|
Temperature |
Allowable temperature of shell |
℃ |
80 |
|||||
|
Maximum operating temperature of fuel tank |
℃ |
70 |
||||||
|
Angle |
Maximum inclination angle of the inclined plate |
° |
± 18 ° |
|||||
|
Weight |
HPV series hydraulic pump Hydraulic oil drainage |
kg |
45 |
46 |
63 |
64 |
87 |
87.5 |
Products Advantages
HPV series closed axial piston pump offers high efficiency, compact design, and long service life, making it the ideal choice for reliable hydraulic systems.
Product Application
The LPV series closed axial piston pump is ideal for applications requiring a reliable and efficient hydraulic power source. Whether it's for industrial machinery, construction equipment, or agricultural vehicles, this pump delivers outstanding performance in demanding environments.
LV90 Closed Axial Piston Pump - Compact Design
Product Description
Designed for challenging industrial environments,HPV110 pump integrates precise axial piston displacement technology. Its optimized rotating group and reinforced bearing arrangement reduce internal leakage and vibration, providing smooth, stable fluid delivery while significantly enhancing overall hydraulic system performance.
Product Details
Its closed axial piston design, it provides reliable performance and long service life. Its compact size makes it ideal for installations where space is limited.
Features
Simplified structure allows easy dismantling, significantly reducing maintenance costs.
Versatile control options: manual, electric, and hydraulic modes easily switchable.
Superior pump body design capable of handling extreme operational conditions.
International standard interfaces ensure excellent compatibility and universality.
Flexible customization options tailored to customer-specific needs.
Product Application
LPV70 Closed Axial Piston Pump is designed for compact spaces and operates efficiently. It is ideal for use in hydraulic systems requiring high pressure and minimal noise output. This pump is suitable for various industrial applications, such as agriculture machinery.
About Us
Shandong Highland Hydraulic Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with nearly 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.
Packing & Delivery
To protect the goods, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.
FAQ
Tell us about your project requirements and we will figure out a solution that will meet your budget and design expectations.
Company Features
· Developing into a large scale enterprise, Shandong Highland Hydraulic Seiko Co., Ltd is well-known in the manufacturing of hydraulic pump swash plate. We have defeated many other competitors and stand at the top.
· With its stable product quality and its brand, Shandong Highland Hydraulic Seiko Co., Ltd has established service networks nation-wide to serve consumers. Shandong Highland Hydraulic Seiko Co., Ltd has built a world-class modern hydraulic pump swash plate factory with product sales and service networks all over the world. Shandong Highland Hydraulic Seiko Co., Ltd has satisfied the need to turn the hi-tech into productivity.
· Over the years, our clients and word-of-mouth referrals have proven to be a huge source of our success. Get price!
Product Comparison
Compared with general products, the hydraulic pump swash plate we produce have the following advantages.
Enterprise Advantages
We have a group of strong, optimistic and motivated employees who carry out multi-channel and multi-level vocational training from time to time to improve their professional ability, professional skills, and promote employee development, laying the foundation for the company's talent team.
Highland Hydraulic has a professional marketing service team. We are able to provide consumers with quality products and services.
Highland Hydraulic will continue to follow the business philosophy of 'survive by quality, gain market by reputation, develop by innovation'. To better develop our company, we also carry forward the enterprise spirit of 'self-improvement, innovation and development, cooperation and win-win'. We sincerely provide quality products and services for new and old customers and now we are looking forward to cooperating with you and creating brilliance!
Incorporated in our company has accumulated a wealth of industry experience and established a comprehensive marketing service network. Therefore, we have shaped a good brand image and enterprise image in the industry.
In addition to the sales to major cities in the country directly, our company's products are also exported to Southeast Asia, South America and some countries and regions.
