Function

Power components of hydraulic system

Brand

HIGHLAND

Operation Mode

Closed Circuit Hydraulic System

Working Medium

Hydraulic Oil

Product details of the hydraulic piston pump

Product Specification

Function: Power components of hydraulic system

Working Medium: Hydraulic Oil

Operation Mode: Closed Circuit Hydraulic System

Brand: HIGHLAND

Product Overview

To maintain its competitiveness, Highland Hydraulic has put large time and energy to designing hydraulic piston pump. The product has been approved by all required international certificates. Our hydraulic piston pump has a wide range of applications and can be used in a variety of situations and scenarios. The application result shows that this product is of practical use.

Product Description

Highland Hydraulic's hydraulic piston pump has the following advantages over products in the same category.

Superior Quality High Pressure Axial Piston Pump

With Advanced Technology

High-pressure axial piston pump is designed for maximum efficiency, durability, and precise fluid control. With advanced technology, it ensures stable operation and reliability in industrial, construction, and hydraulic applications.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

LPV70 Axial Piston Pumps are engineered for superior energy efficiency and reliable operation under intensive workloads. Their precision-engineered displacement control system ensures optimal performance with reduced energy consumption. Equipped with corrosion-resistant and wear-resistant materials, LPV70 pumps maintain sustained efficiency and exceptional durability, making them a preferred choice for heavy-duty hydraulic operations in construction, mining, and industrial sectors.

Product Features

-Closed-Loop Hydraulic Circuit:Enables precise fluid control, reduces energy loss, and improves overall hydraulic system responsiveness.
-Variable Displacement Swash Plate: Offers dynamic flow adjustment capability, optimizing system efficiency under varying load conditions.
- Integrated Charge Pump: Maintains stable inlet pressure, preventing cavitation and enhancing pump reliability.
- High-Pressure Shaft Seals: Ensures superior leak-tightness, significantly extending maintenance intervals.
- Hardened Cylinder Block: Provides exceptional wear resistance under continuous high-pressure operation, ensuring pump longevity.

Product INTRODUCTION

With its compact form factor, the LPV70 integrates effortlessly into space-constrained installations. The pump's streamlined, easily accessible construction simplifies maintenance, enhances reliability, and reduces potential leak points, contributing to overall system longevity.

Product specification

Rated displacement			30	50	70	90	110	130
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
Torque	Maximum output torque	Nm	227	353	480	606	749	885
power	Continuous Power	KW	41	72	98	128	137	162
power	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

HPV30(50)

PDF

HPV70（90）

PDF

HPV110(130)

PDF

detail displaY

High Pressure Axial Piston Pump

HPV70 Hydrostatic Piston Pump

High Pressure Axial Piston Pump

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To protect the goods, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.

Company Advantages

situated in de zhou, mainly manages the business of Hydraulic pump、Hydraulic motor、Hydraulic test benches. Highland Hydraulic not only produces high-quality products but also provide professional after-sales services. We are committed to providing customers with quality products. We sincerely welcome customers with needs to contact us, and look forward to establishing a long-term friendly relation with you!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
