Hydraulic Piston Motor 40kg Wholesale - Highland Hydraulic

Delivery Time:

According to customers' quantity

Inquiry

Hydraulic Motor Mode

HMF90

Weight

40kg

Displacement

90ml/r

Working Medium

Hydraulic Oil

Product details of the hydraulic piston motor

Product Specification

Displacement: 90ml/r

Weight: 40kg

Working Medium: Hydraulic Oil

Hydraulic Motor Mode: HMF90

Product Introduction

The design of Highland Hydraulic hydraulic piston motor is original and appealing. In order to ensure its durability, the extra add quality testing is added to the production. hydraulic piston motor produced by Highland Hydraulic enjoys a high reputation among customers.

HIGHLAND MF SERIES

Closed Circuit Axial Piston Motor Fixed displacement hydraulic motor for closed loop operation

Products Advantages

MF series closed circuit axial piston motor is built to deliver a reliable, high-performance solution for your closed-circuit systems.

Hydraulic Piston Motor 40kg Wholesale - Highland Hydraulic 8

Product Design

Delivers up to 3800 r/min to meet demanding applications.

Hydraulic Piston Motor 40kg Wholesale - Highland Hydraulic 9

Low price

We promise the lowest price for new products of the same variety in the world

Hydraulic Piston Motor 40kg Wholesale - Highland Hydraulic 10

Simplified External Design

Integrated rear cover with protection and wash valves, reducing external setup.

Universal Mounting Compatibility

International standards for installing flanges, shafts, and ports

Product Application

MF series closed axial piston motor is perfect for heavy-duty industrial applications, such as construction machinery and mining equipment. Its high efficiency and reliable performance make it the ideal choice for demanding working environments.

Asphalt side feeder machine

harvester

rice harvester

Hydraulic walking rice harvester

Product Description

The rotational speed of the mixer drum hydraulic motor is directly proportional to the supplied hydraulic fluid flow, allowing precise speed control.

HIGHLAND MF23 Hydraulic Piston Motor 42Mpa

MAIN FEATURES

Sealed leak-proof construction
Long-term continuous duty cycle
Pressure-compensated motor shaft seal

Product Specifications

Rated displacement	MF Series Hydraulic motor model		20	22	23	110
Rated displacement	Maximum displacement	ml/r	33.3	69.8	89	110.8
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3200	3000	3000
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	143	334	430	621
Torque	Maximum output torque	Nm	167	390	502	725
Power	Maximum power	KW	56	131	157	212
Temperature	Allowable temperature of shell	℃	-40 to 50
Temperature	Maximum operating temperature of fuel tank	℃	80
Weight	MF series hydraulic motor Hydraulic oil drainage	kg	34	42	49	49

MF20

PDF

MF22

PDF

MF23

PDF

MF110

PDF

mf series related hydraulic components

MF22 Axial Piston Moto

800x800MF马达-81

About Us

Shandong Highland Hydraulic Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with nearly 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.

Packing & Delivery

To protect the goods, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydraulic pump 2.Hydraulic motor 3.Hydraulic test bench 4.Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=1000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.

Company Advantage

• Established in Highland Hydraulic has gone through a major change in the past years.
• Traffic convenience including easy and open highway access and the great geographic location is conducive to the transportation of Hydraulic pump、Hydraulic motor、Hydraulic test benches.
• Highland Hydraulic's Hydraulic pump、Hydraulic motor、Hydraulic test benches are not only sold in Mainland China, but also exported to some countries and regions overseas. We enjoy a relatively wide recognition in the industry.
Highland Hydraulic is a pharmaceutical company focused on integrity and credit. Hydraulic pump、Hydraulic motor、Hydraulic test benches are of reliable quality and reasonable price. If needed, feel free to contact us.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
