Closed loop hydraulic pump/hydraulic motor manufacturer & hydraulic solutions provider - Highland Hydraulic

Hydraulic Axial Piston Motor Axial Piston Motor - - Highland Hydraulic 1

Hydraulic Axial Piston Motor Axial Piston Motor - - Highland Hydraulic 2

Hydraulic Axial Piston Motor Axial Piston Motor - - Highland Hydraulic 3

Hydraulic Axial Piston Motor Axial Piston Motor - - Highland Hydraulic 4

Hydraulic Axial Piston Motor Axial Piston Motor - - Highland Hydraulic 5

Hydraulic Axial Piston Motor Axial Piston Motor - - Highland Hydraulic 6

Hydraulic Axial Piston Motor Axial Piston Motor - - Highland Hydraulic 7

Hydraulic Axial Piston Motor Axial Piston Motor - - Highland Hydraulic

Packaging Details:

Plywood case

Certificate:

CE ISO9001

Inquiry

more products

Hydrostatic Pump

Hydrostatic Motor

Hydraulic Test Bench

Portable Hydraulic Tester

Send your inquiry

Function

Execution components of hydraulic system

Type

Axial piston motor

Working Medium

Hydraulic Oil

Product details of the hydraulic axial piston motor

Product Specification

Working Medium: Hydraulic Oil

Function: Execution components of hydraulic system

Type: Axial piston motor

Product Introduction

Highland Hydraulic hydraulic axial piston motor meets rigorous standards for quality and consistency. The quality of this product is always put in the first place by our strict QC team. It has distinguished competitiveness and has received much attention.

Advanced hydrostatic transmission

hydrostatic motor for superior efficiency

Our hydrostatic transmission and motor system provide efficient, precise,

and reliable hydraulic power transfer. With smooth operation, high torque output, and durable construction.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Widely Application

Agricultural equipment, and other heavy machinery, providing precise control and long-lasting performance.

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

HIGHLAND advanced hydrostatic motor and transmission system provide smooth, efficient, and precise hydraulic power transfer, making it ideal for heavy-duty applications. It minimizes energy loss while ensuring optimal performance. With a compact design and durable construction, it withstands demanding industrial conditions. This hydrostatic solution enhances productivity while reducing maintenance costs.

Product Features

Hydrostatic transmission and hydrostatic motor system deliver outstanding efficiency and precision in power transmission.
Engineered for industrial, agricultural, and construction machinery.
Hydrostatic motor provide excellent load adaptability, reducing energy loss and improving overall performance.
Their robust construction ensures durability, even in harsh working conditions.
With low maintenance requirements and enhanced operational efficiency.

Product INTRODUCTION

Designed for high efficiency and reliability, HIGHLAND hydrostatic transmission and motor system ensure smooth power delivery and superior performance. The system allows precise speed and torque control, improving operational efficiency in various industrial applications. Its durable design and advanced hydraulic technology make it a preferred choice for demanding environments.

MF110 Axial Piston Motors 42mpa HIGHLAND

MF series motor Product Specifications

Rated displacement			20	22	23	110
Rated displacement	Maximum displacement	ml/r	33.3	69.8	89	110.8
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3200	3000	3000
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	143	334	430	621
Torque	Maximum output torque	Nm	167	390	502	725
Power	Maximum power	KW	56	131	157	212
Temperature	Allowable temperature of shell	℃	-40 to 50
Temperature	Maximum operating temperature of fuel tank	℃	80
Weight	MF series hydraulic motor Hydraulic oil drainage	kg	34	42	49	49

MF20

PDF

MF22

PDF

MF23

PDF

MF110

PDF

detail displaY

MF23 Hydraulic Motor

Hydraulic Motor Manufacturer

Industrial Hydraulic Motor

Product Application

Concrete Mixer Truck

Cotton Picker

Engineering Ship

Cane Grabber Machine

Packing & Delivery

To protect the goods, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.

Company Advantage

• Highland Hydraulic has advantageous conditions for product delivery. Nearby there is a prosperous market, developed communication, and traffic convenience.
• Highland Hydraulic has established trade relations with many companies at home and abroad.
• After years of hard work, our company has been continuously increasing our business, enhancing our strength and expanding our scale. Now we have become the top company in the industry.
• Highland Hydraulic runs the business in good faith and strives to provide quality services for customers.
Welcome customers and friends who are in need to contact us and look forward to reaching a friendly cooperation with you!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
