Brand

HIGHLAND

Speed

3200r/min

Material

Cast Iron

Product details of the closed circuit hydraulic pump

Product Specification

Material: Cast Iron

Brand: HIGHLAND

Speed: 3200r/min

Product Overview

In terms of the design, the closed circuit hydraulic pump is very competitive. It is qualified with many international certification. Highland Hydraulic's closed circuit hydraulic pump can be used in many industries. If you have any problem about closed circuit hydraulic pump, please feel free to contact our professional service team.

Product Description

Compared with products in the same category, closed circuit hydraulic pump we produce is equipped with the following advantages.

Factory Price Hydraulic Piston Pump PV22 For Cement Mixer

Hydraulic piston pump PV22 is a high-pressure hydraulic pump designed for industrial and mobile applications.

It offers high efficiency, high performance, and smooth operation with direct sale and fast delivery from the manufacturer.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

PV22 Axial Piston Pump is perfectly suited for concrete mixer trucks requiring high performance in compact spaces. Its robust, space-saving design ensures exceptional hydraulic efficiency, simple installation, and reduced maintenance efforts, making it ideal for demanding environments.

Product Features

PV22 Hydraulic Axial Piston Pump is engineered precisely for concrete mixer trucks, delivering consistent hydraulic flow and exceptional operational stability under demanding workloads.
Featuring advanced piston design, PV22 offers superior volumetric efficiency, significantly lowering fuel consumption and operational costs.
Constructed using robust, corrosion-resistant materials, the PV22 pump ensures extended durability, providing reliable performance even under harsh environmental conditions.
PV22 Hydraulic Piston Pump provides precise pressure control and smooth hydraulic responsiveness, ensuring consistently high productivity and optimal mixing quality.

Product INTRODUCTION

Purpose-built for high-pressure durability, the PV23 pump thrives under the relentless conditions typical in concrete mixer truck applications. Its sturdy construction and modular design make it a versatile choice, easily accommodating integration and ongoing maintenance within modern hydraulic systems.

PRODUCT SPECIFICATIONS

Rated displacement			20	22	23	110
Rated displacement	Maximum displacement	ml/r	33.3	69.8	89	110.8
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3200	2700	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	342.6	432.9	535.3
Torque	Maximum output torque	Nm	227	480	606	749
Power	Continuous Power	KW	41	98	128	137
Power	Maximum power	KW	57	105	138	159
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	PV series hydraulic pump Hydraulic oil drainage	kg	45	63	79	79

Button

PV20

PDF

PV22

PDF

PV23

PDF

PV110

PDF

detail displaY

Hydraulic Pump PV22

Hydraulic Piston Pump PV22

Cement Mixer Hydraulic Pump

Product Application

6-12 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine
