Axial Variable Displacement Pump Western Union by Highland Hydraulic
Product details of the axial variable displacement pump
Product Specification
Working Medium: Hydraulic Oil
Characteristic: High efficiency
Quick Overview
Highland Hydraulic axial variable displacement pump is designed by a team of professionals. They evaluate the product in a short time according to the needs and put forward the most appropriate design concept and complete it. This product has stable performance and long service life. The axial variable displacement pump developed by Highland Hydraulic is widely used in various fields. Shandong Highland Hydraulic Seiko Co., Ltd always manages to make sure customers are getting what they need.
Product Description
Our axial variable displacement pump is more competitive than similar products, as shown in the following aspects.
Fast delivery high efficiency hydraulic piston pump for construction equipment
our advantage
Product Description
High-efficiency hydraulic piston pump delivers precise and consistent fluid flow, optimizing power transmission in construction equipment. It features a rugged build with wear-resistant components for extended service life. Its advanced hydraulic system minimizes energy loss while maximizing pressure output, ensuring stable and efficient operation. Hydraulic pump is engineered for fast delivery, ensuring minimal lead times for urgent projects.
Product Features
- Hydraulic piston pump is built for high-performance construction equipment, providing exceptional efficiency and reliability.
- With a robust design and advanced hydraulic technology, it optimizes energy consumption, reduces heat generation, and enhances operational stability.
- Designed for fast delivery, it minimizes downtime, keeping construction projects on schedule. Ideal for excavators, bulldozers, cranes, and other heavy-duty machinery, this hydraulic pump ensures superior hydraulic performance.
Product INTRODUCTION
Designed for heavy-duty construction machinery, this high-efficiency hydraulic piston pump offers superior durability, energy savings, and reliable performance. Its fast delivery and optimized design make it ideal for demanding applications, ensuring uninterrupted operation and reduced maintenance costs.
PRODUCT SPECIFICATIONS
|
Rated displacement |
|
20 |
22 |
23 |
110 |
|
|
Maximum displacement |
ml/r |
33.3 |
69.8 |
89 |
110.8 |
|
|
Speed |
Maximum continuous operating speed (Full load condition) |
r/min |
3500 |
3200 |
2700 |
2700 |
|
Rated speed |
r/min |
2500 |
|
|||
|
Minimum continuous operating speed |
r/min |
500 |
|
|||
|
Pressure |
Rated working pressure |
Mpa |
35 |
|
||
|
Maximum working pressure (instantaneous) |
Mpa |
42 |
|
|||
|
Continuous working pressure ( Δ P) |
Mpa |
30 |
|
|||
|
Allowable shell pressure (absolute) |
Mpa |
Constant0.25，Peak value0.5 |
|
|||
|
Torque |
Continuous output torque (Under continuous work pressure) |
Nm |
162.3 |
342.6 |
432.9 |
535.3 |
|
Maximum output torque |
Nm |
227 |
480 |
606 |
749 |
|
|
Power |
Continuous Power |
KW |
41 |
98 |
128 |
137 |
|
Maximum power |
KW |
57 |
105 |
138 |
159 |
|
|
Temperature |
Allowable temperature of shell |
℃ |
80 |
|
||
|
Maximum operating temperature of fuel tank |
℃ |
70 |
|
|||
|
Angle |
Maximum inclination angle of the inclined plate |
° |
± 18 ° |
|
||
|
Weight |
PV series hydraulic pump Hydraulic oil drainage |
kg |
45 |
63 |
79 |
79 |
detail displaY
Product Application
About Us
Shandong Highland Hydraulic Seiko Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with more than 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.
Packing & Delivery
To protect hydrostatic pump, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.
FAQ
Company Introduction
Shandong Highland Hydraulic Seiko Co., Ltd is a new type of company. The business range covers from manufacturing to sales and service. The main products include Hydraulic pump、Hydraulic motor、Hydraulic test benches. Our company follows the business concept of 'integrity-based, genuine goods, quality first, customer first'. In addition, we practice the spirit of 'dedicated, concentration, profession'. We undertake a first-class industrial brand building as our duty, and improve our international influence, so as to become a China-oriented and leading company in the world. Highland Hydraulic has a high-quality management team, excellent R & D team, intimate service team, and also set up a professional distribution team to provide a good guarantee for product development, sales services, transportation, and distribution. We have been engaged in the production and management of Hydraulic pump、Hydraulic motor、Hydraulic test benches for many years. For some problems encountered by customers in the procurement, we have the ability to provide customers with a practical and effective solution to help customers solve problems better.
If you want to purchase our products in bulk, feel free to contact us.
