Axial Variable Displacement Pump HIGHLAND by Highland Hydraulic

Company Advantages

· The aesthetic appearance of axial variable displacement pump is achieved by using quality materials and the latest technologies.

· Highland Hydraulic takes the pledge for the quality and service life of products.

· Shandong Highland Hydraulic Seiko Co., Ltd's products are all 100% guaranteed by high quality foreign brands.

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

PRODUCT SPECIFICATIONS

Rated displacement			30	50	70	90	110	130
	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
	Maximum output torque	Nm	227	353	480	606	749	885
Power	Continuous Power	KW	41	72	98	128	137	162
	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

Read More

Download FIle

PDF

Download FIle

HPV30(50)

PDF

HPV70（90）

PDF

HPV110(130)

PDF

Product Description

HPV110 axial piston pumps are equipped with advanced pressure compensation mechanisms, offering accurate and dynamic flow adjustments under varying load conditions.** Utilizing high-performance materials and precise manufacturing techniques, these pumps effectively minimize heat generation and maximize mechanical efficiency in continuous-duty industrial applications.

Product Features

International standard interface for simple and fast installation.

Modular control valves allow flexible customization and replacement.

High-strength materials ensure excellent impact resistance of the pump body.

Fully customizable to meet specific customer requirements.

Commitment to delivering highest performance at the lowest possible cost.

Product INTRODUCTION

HPV110 hydraulic pump is engineered to meet the rigorous demands of industrial machinery. With a sophisticated variable displacement mechanism and robust slipper-piston construction, it ensures exceptional hydraulic stability, smooth output flow, and minimal internal friction losses, optimizing energy consumption and extending equipment lifespan.

detail displaY

Closed Circuit System

Harvester Hydraulic Piston Pump

Closed Circuit Hydraulic Pump

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To protect the goods, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.

Company Features

· Shandong Highland Hydraulic Seiko Co., Ltd is the main provider of axial variable displacement pump in China. We also offer a wide range of product portfolio.

· With a full commitment to improving customer services, we finally win many loyal customers and establish stable business cooperations with them. We take time to evaluate our services, make sure we respond to our customers timely about any problems related to the products. At present, we have formed a strong customer base. We have a deep understanding of our clients' needs and insights into potential customers. This allows us to develop services that are matched to clients' needs. We have many excellent and united staffs. They feature high dependability, positivity, and self-motivation. These features encourage them to keep setbacks in perspective, persevere to improve their resilience. We believe they are the best team to offer services to clients.

· We think sustainability is of great importance. Through our investments in sectors such as water supply, wastewater treatment systems, and sustainable energy, we make a real difference to the environment. Contact!

Application of the Product

axial variable displacement pump of Highland Hydraulic can be widely used in various fields.

With a focus on Hydraulic pump、Hydraulic motor、Hydraulic test benches, Highland Hydraulic is dedicated to providing reasonable solutions for customers.

Enterprise Advantages

To guarantee the high quality production, our company has established a skilled team with modern enterprise quality. During the production, our team members are focusing on their own duties.

Highland Hydraulic has always been dedicated to providing quality services based on customer demand.

Highland Hydraulic holds the enterprise spirit of 'integrity, pragmatism, breakthrough, and tenacity'. During the development, we focus on sincere service and maintain a pragmatic way. We also seek breakthrough and proactively assume social responsibility. All difficulties are overcame based on tenacity.

Set up in Highland Hydraulic has developed in the industry for years and has mastered the advanced technology.

Highland Hydraulic's products are of good quality and excellent safety. They are highly praised by consumers and are even exported to many foreign countries including
