Product details of the axial piston type hydraulic pump
Product Specification
Working Medium: Hydraulic Oil
Operation Mode: Closed Circuit Hydraulic System
Function: Execution components of hydraulic system
Brand: HIGHLAND
Quick Detail
Highland Hydraulic axial piston type hydraulic pump is finely and expertly manufactured in a combination of abundant expertise and advanced production technology. The quality and authenticity of the product are guaranteed highly. Highland Hydraulic's axial piston type hydraulic pump can be used in many industries. The product has improved its popularity and reputation rapidly since it was launched.
Product Description
The axial piston type hydraulic pump of Highland Hydraulic has the following advantages compared with axial piston type hydraulic pump in the market.
ISO9001 Certified Closed Circuit Hydraulic Pump
For Marine Aplication
our advantage
Product Description
Engineered for marine environments, this hydraulic pump offers high performance and durability. Its closed-circuit design ensures high efficiency and precise fluid control. Hydraulic pump is made of corrosion-resistant materials, ensuring long-term operation in harsh conditions.
Product Features
Product INTRODUCTION
Designed for demanding marine applications, ISO9001-certified closed-circuit hydraulic pump ensures exceptional performance, efficiency, and durability. Its high-quality construction and precision engineering provide reliable fluid control in ship propulsion, steering systems, and other marine hydraulic operations.
PRODUCT SPECIFICATIONS
Rated displacement |
|
20 |
22 |
23 |
110 |
|
Maximum displacement |
ml/r |
33.3 |
69.8 |
89 |
110.8 |
|
Speed |
Maximum continuous operating speed (Full load condition) |
r/min |
3500 |
3200 |
2700 |
2700 |
Rated speed |
r/min |
2500 |
|
|||
Minimum continuous operating speed |
r/min |
500 |
|
|||
Pressure |
Rated working pressure |
Mpa |
35 |
|
||
Maximum working pressure (instantaneous) |
Mpa |
42 |
|
|||
Continuous working pressure ( Δ P) |
Mpa |
30 |
|
|||
Allowable shell pressure (absolute) |
Mpa |
Constant0.25,Peak value0.5 |
|
|||
Torque |
Continuous output torque (Under continuous work pressure) |
Nm |
162.3 |
342.6 |
432.9 |
535.3 |
Maximum output torque |
Nm |
227 |
480 |
606 |
749 |
|
Power |
Continuous Power |
KW |
41 |
98 |
128 |
137 |
Maximum power |
KW |
57 |
105 |
138 |
159 |
|
Temperature |
Allowable temperature of shell |
℃ |
80 |
|
||
Maximum operating temperature of fuel tank |
℃ |
70 |
|
|||
Angle |
Maximum inclination angle of the inclined plate |
° |
± 18 ° |
|
||
Weight |
PV series hydraulic pump Hydraulic oil drainage |
kg |
45 |
63 |
79 |
79 |
detail displaY
Product Application
About Us
Shandong Highland Hydraulic Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with nearly 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.
Packing & Delivery
To protect hydrostatic pump, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.
FAQ
Company Advantages
Shandong Highland Hydraulic Seiko Co., Ltd is a diversified company in the industry. The main business is focused on Hydraulic pump、Hydraulic motor、Hydraulic test benches. Complying with the core value, Highland Hydraulic devotes ourselves to the sincerity-based business and seeks development with innovation. Quality and customers are always our priority in the people-oriented business operation. With science and technology as the guide and the advantages of technology and management as the basis, we create a first-class brand in the industry and constantly provide quality products and services. Highland Hydraulic has high-quality teams that understand technology and knows well about management, which lays a solid foundation for the development and growth. We are willing to understand the real needs of our customers. Then, we will provide the best solutions to their needs.
Welcome everyone to come for consultation.
