Axial Piston Pump Manufacturers Closed Circuit Hydraulic System - - Highland Hydraulic

Product details of the axial piston pump manufacturers

Product Specification

Material: Cast Iron

Operation Mode: Closed Circuit Hydraulic System

Type: Axial piston pump

Characteristic: High efficiency

Product Description

Such design will certainly make axial piston pump manufacturers even more appealing to customers. The product is superior in terms of performance, durability, and so on. Highland Hydraulic's R&D team specializes in the design of highly stable axial piston pump manufacturers products.

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Highland high-efficiency piston plunger pumps provides powerful, consistent hydraulic support for transit mixers. Built to operate continuously in harsh construction conditions, it enhances drum rotation efficiency and reduces fuel usage with minimal maintenance needs.

Product Features

• High Efficiency Piston Plunger Pumps for Transit Mixers is engineered to meet the demanding needs of concrete transportation.

• Highland Plunger Pumps ensures stable and high-pressure hydraulic output to power the rotation and tilt mechanisms of the mixer drum.

• Piston Pumps enhanced sealing technology prevents leakage and minimizes wear, while the easy maintenance structure reduces downtime.

Product INTRODUCTION

Designed for transit mixers, Highland piston plunger pumps offers reliable hydraulic power with high volumetric efficiency. Its rugged build ensures performance in extreme conditions, while its compact design fits seamlessly into tight equipment layouts. Ideal for heavy-duty concrete transport.

PRODUCT SPECIFICATIONS

Rated displacement			20	22	23	110
	Maximum displacement	ml/r	33.3	69.8	89	110.8
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3200	2700	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	342.6	432.9	535.3
	Maximum output torque	Nm	227	480	606	749
Power	Continuous Power	KW	41	98	128	137
	Maximum power	KW	57	105	138	159
Temperature	Allowable temperature of shell	℃	80
	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	PV series hydraulic pump Hydraulic oil drainage	kg	45	63	79	79

Read More

PV20

PDF

PV22

PDF

PV23

PDF

PV110

PDF

detail displaY

Piston Pumps

Plunger Pumps

Piston Plunger Pumps

Product Application

6-12 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine
