Axial Piston Pump Fixed Displacement 40kg - - Highland Hydraulic
Company Advantages
· After many times of iterations, sole weight of axial piston pump fixed displacement'body frame is effectively decreased.
· Strict quality control ensures that the quality and performance of the product meets industry specifications.
· Products from Shandong Highland Hydraulic Seiko Co., Ltd are sold well to overseas market.
HIGHLAND MF SERIES
Closed Circuit Axial Piston Motor Fixed displacement hydraulic motor for closed loop operation
Products Advantages
MF series closed circuit axial piston motor is built to deliver a reliable, high-performance solution for your closed-circuit systems.
Product Application
MF series closed axial piston motor is perfect for heavy-duty industrial applications, such as construction machinery and mining equipment. Its high efficiency and reliable performance make it the ideal choice for demanding working environments.
Product Description
Concrete mixer hydraulic motors typically employ radial piston designs, delivering high torque at low speeds, ideal for heavy-duty mixing applications.
MAIN FEATURES
- Radial piston motor structure
- High torque and low-speed performance
- Enhanced radial load capacity
Product Specifications
|
Rated displacement |
MF Series Hydraulic motor model |
20 |
22 |
23 |
110 |
|
|
Maximum displacement |
ml/r |
33.3 |
69.8 |
89 |
110.8 |
|
|
Speed |
Maximum continuous operating speed (Full load condition) |
r/min |
3500 |
3200 |
3000 |
3000 |
|
Rated speed |
r/min |
2500 |
||||
|
Minimum continuous operating speed |
r/min |
500 |
||||
|
Pressure |
Rated working pressure |
Mpa |
35 |
|||
|
Maximum working pressure (instantaneous) |
Mpa |
42 |
||||
|
Continuous working pressure ( Δ P) |
Mpa |
30 |
||||
|
Allowable shell pressure (absolute) |
Mpa |
Constant0.25，Peak value0.5 |
||||
|
Torque |
Continuous output torque (Under continuous work pressure) |
Nm |
143 |
334 |
430 |
621 |
|
Maximum output torque |
Nm |
167 |
390 |
502 |
725 |
|
|
Power |
Maximum power |
KW |
56 |
131 |
157 |
212 |
|
Temperature |
Allowable temperature of shell |
℃ |
-40 to 50 |
|||
|
Maximum operating temperature of fuel tank |
℃ |
80 |
||||
|
Weight |
MF series hydraulic motor Hydraulic oil drainage |
kg |
34 |
42 |
49 |
49 |
mf series related hydraulic components
About Us
Shandong Highland Hydraulic Co., Ltd. is one of China's largest hydraulic enterprises, covering 10,000㎡ with nearly 20 years of experience. We specialize in hydraulic pumps, motors, testers, and test benches for industries like agriculture, engineering, shipbuilding, mining, and oil exploration. With strong R&D, advanced equipment, and over 20 patents, we have customized hydraulic systems and test benches for 6,000+ enterprises. Our products serve OEMs and repair companies worldwide, including America, Europe, and Asia, recognized for quality, service, and competitive pricing. We look forward to long-term, mutually beneficial cooperation.
Packing & Delivery
To protect the goods, we pack and fix goods at least two layers. The first layer is plastic bag to protect against moisture, the second is to fix hydrostatic pump in the plywood case because its heavy goods, the third is plywood case, standard export package.
FAQ
Company Features
· Highland Hydraulic is a brand of professional axial piston pump fixed displacement manufacturer in China.
· The coordinated development of technology development and research will ensure the quality of axial piston pump fixed displacement.
· Our business philosophy is to win the market through quality and service. All of our teams are working hard to create value for customers, no matter helping cut production costs or improving product quality. We hope to win their trust by doing these.
Product Comparison
Compared with similar products, Highland Hydraulic's axial piston pump fixed displacement has the following advantages.
Enterprise Advantages
Highland Hydraulic constructed an outstanding talents team in the process of business development. The team members are united, cooperative, and efficient.
Our company has established a comprehensive product supply and after sales service system. To enhance sense of relying for us, we are persevering in offering thoughtful service for every customer.
With the main focus on quality, Highland Hydraulic strives for excellence and steady development. We think highly of integrity and sincerity, which is the foundation for us to gain mutual benefit. Strict quality control and focus on customers are of great importance to corporate development. We strive to build a first-class brand and become a leader in the industry.
So far, Highland Hydraulic has developed the business for years. During the years, we have gained frustrations as well as achievements. Moreover, we have chased and achieved our dreams.
At the moment, our company's sales network has spread all over the country's major cities and regions. In the future, we will strive to open up a broader overseas market.
