Application

Mixer Truck

Function

Execution components of hydraulic system

Brand

HIGHLAND

Displacement

90ml/r

Working Medium

Hydraulic Oil

Product details of the axial piston hydraulic motor

Product Specification

Function: Execution components of hydraulic system

Displacement: 90ml/r

Brand: HIGHLAND

Working Medium: Hydraulic Oil

Application: Mixer Truck

Product Information

Highland Hydraulic axial piston hydraulic motor is manufactured in strict line with the production procedure. The quality of this product is one of the best due to the adoption of the strict quality control system. Shandong Highland Hydraulic Seiko Co., Ltd has developed a broad market at home and abroad with its excellent quality, fast delivery, and timely and thoughtful service.

HIGHLAND MF SERIES

Closed Circuit Axial Piston Motor Fixed displacement hydraulic motor for closed loop operation

Products Advantages

MF series closed circuit axial piston motor is built to deliver a reliable, high-performance solution for your closed-circuit systems.

Axial Piston Hydraulic Motor Execution Components of Hydraulic System - - Highland Hydraulic 8

Product Design

Delivers up to 3800 r/min to meet demanding applications.

Axial Piston Hydraulic Motor Execution Components of Hydraulic System - - Highland Hydraulic 9

Low price

We promise the lowest price for new products of the same variety in the world

Axial Piston Hydraulic Motor Execution Components of Hydraulic System - - Highland Hydraulic 10

Simplified External Design

Integrated rear cover with protection and wash valves, reducing external setup.

Universal Mounting Compatibility

International standards for installing flanges, shafts, and ports

Product Application

MF series closed axial piston motor is perfect for heavy-duty industrial applications, such as construction machinery and mining equipment. Its high efficiency and reliable performance make it the ideal choice for demanding working environments.

Asphalt side feeder machine

harvester

rice harvester

Hydraulic walking rice harvester

Product Description

The rotational speed of the mixer drum hydraulic motor is directly proportional to the supplied hydraulic fluid flow, allowing precise speed control.

HIGHLAND MF23 Hydraulic Piston Motor 42Mpa

MAIN FEATURES

Sealed leak-proof construction
Long-term continuous duty cycle
Pressure-compensated motor shaft seal

Product Specifications

Rated displacement	MF Series Hydraulic motor model		20	22	23	110
Rated displacement	Maximum displacement	ml/r	33.3	69.8	89	110.8
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3200	3000	3000
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	143	334	430	621
Torque	Maximum output torque	Nm	167	390	502	725
Power	Maximum power	KW	56	131	157	212
Temperature	Allowable temperature of shell	℃	-40 to 50
Temperature	Maximum operating temperature of fuel tank	℃	80
Weight	MF series hydraulic motor Hydraulic oil drainage	kg	34	42	49	49

MF20

PDF

MF22

PDF

MF23

PDF

MF110

PDF
