Closed loop hydraulic pump/hydraulic motor manufacturer & hydraulic solutions provider - Highland Hydraulic

Key Features and Applications Of Hydraulic Piston Pumps 6

Key Features and Applications Of Hydraulic Piston Pumps

1. High Efficiency: Offers excellent volumetric and mechanical efficiency for optimal energy use.

2. High Pressure Capability: Can operate at pressures exceeding 420 Bar, making them ideal for heavy-duty systems.

3. Durable Design: Built with high-quality materials to ensure long service life even in extreme conditions.

4. Precise Flow Control: Provides accurate flow and pressure adjustment for enhanced system performance.

5. Versatile Application: Suitable for closed circuit systems in various industries including construction, agriculture, and marine.

MOQ:

1 set

Packaging Details:

Plywood case

Delivery Time:

30-60 work days

Payment Terms:

T/T, Western Union

Supply Ability:

100 sets per month

Certificate:

CE ISO9001

Inquiry

Write a Review

Hydraulic Pump Mode

HPV110

Product Name

Variable Hydraulic Pump

Application

Harvesting machinery

Type

Axial piston pump

Pressure

42mpa

Brand

HIGHLAND

Operation Mode

Closed Circuit Hydraulic System

Working Medium

Hydraulic Oil

Warranty

1 Year

Material

Cast Iron

Key Features and Applications Of Hydraulic Piston Pumps

Hydraulic piston pumps offer high efficiency, durability, and precision, making them essential for heavy-duty

and high-pressure hydraulic systems across various industries.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Key Features Of Hydraulic piston pumps deliver high-pressure hydraulic fluid using reciprocating pistons. Ideal for demanding applications, they offer superior efficiency, high power output, and precise control. These hydraulic pumps pumps are built to handle continuous operation in rugged environments.

Product Features

Applications Of Hydraulic piston pumps are widely used in industries requiring high power density and precision, such as construction, agriculture, mining, and manufacturing.
These hydraulic piston pumps work by using reciprocating pistons to move hydraulic fluid under high pressure, enabling the operation of heavy machinery and equipment.
They are favored for their efficiency, reliability, and ability to operate under high pressure and variable flow rates.

Product INTRODUCTION

Highland hydraulic piston pumps play a critical role in modern hydraulic systems. Designed for efficiency and durability, they are capable of producing high pressures and supporting variable flow needs. Their robust construction makes them suitable for industrial, mobile, and heavy-duty applications.

PRODUCT SPECIFICATIONS

Rated displacement			30	50	70	90	110	130
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
Torque	Maximum output torque	Nm	227	353	480	606	749	885
Power	Continuous Power	KW	41	72	98	128	137	162
Power	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

HPV30(50)

PDF

HPV70(90)

PDF

HPV110(130)

PDF

detail displaY

High Pressure Hydraulic Piston Pumps

Key Features Of Hydraulic Piston Pumps

Applications Of Hydraulic Piston Pumps

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To ensure the safe delivery of variable piston pump and hydraulic motor, we utilize multiple layers of protective packaging. The pump is first sealed in a durable plastic bag to prevent moisture and contamination. Next, it is securely fixed within a reinforced plywood case to prevent movement and damage during transportation, given the heavy weight of the product. Finally, the plywood case, built to standard export specifications, provides sturdy protection suitable for international shipping.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.
