Closed loop hydraulic pump/hydraulic motor manufacturer & hydraulic solutions provider - Highland Hydraulic

Hydraulic Pumps Motors Supplier for Industrial And Mobile Applications

Hydraulic Pumps Motors for Industrial Applications

Hydraulic Pumps Motors for Mobile Applications

Hydraulic Pumps Motors Supplier For Industrial And Mobile Applications

Wide Application Range: Offering hydraulic pumps motors for industrial machinery, mobile equipment.
High Efficiency Performance: Designed for optimal energy use, ensuring smooth operation and reduced fuel or power consumption.
Durability Reliability: Built with robust materials precision engineering to withstand harsh working conditions.
Custom Solutions Available: Tailored configurations to meet specific requirements in construction, agriculture, and mobile equipment.
Low Maintenance Design: Engineered with simplified servicing and long service life to minimize downtime and operating costs.

Inquiry

Write a Review

Hydraulic Pumps Motors Supplier

For Industrial And Mobile Applications

Reliable supplier of hydraulic pumps and motors for industrial and mobile applications,

providing efficient, durable, and cost-effective power solutions.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Highland supplier of high quality hydraulic pumps and motors for industrial and mobile applications. Our hydraulic pumps motors provide reliable power, high efficiency, and long service life for demanding machinery needs.

Product Features

As a professional hydraulic pumps and motors supplier, Highland provide high performance hydraulic solutions for both industrial and mobile machinery.
Highland hydraulic pumps motors are designed to deliver maximum efficiency and durability, ensuring stable operation in construction, agriculture, mining, and other demanding environments.
Whether for stationary industrial systems or mobile equipment, Highland hydraulic pumps and motors guarantee consistent performance and long-lasting reliability.

Product INTRODUCTION

Highland supply hydraulic pumps and motors engineered for industrial and mobile applications. With strong performance, durability, and efficiency, our hydraulic solutions support heavy machinery across agriculture, construction, and industrial sectors.

PRODUCT SPECIFICATIONS

Rated displacement			30	50	70	90	110	130
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
Torque	Maximum output torque	Nm	227	353	480	606	749	885
Power	Continuous Power	KW	41	72	98	128	137	162
Power	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

HPV30(50)

PDF

HPV70(90)

PDF

HPV110(130)

PDF

detail displaY

Hydraulic Pumps Motors Supplier

Industrial Hydraulic Power Solutions

Mobile Hydraulic System Components

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To ensure the safe delivery of variable piston pump and hydraulic motor, we utilize multiple layers of protective packaging. The pump is first sealed in a durable plastic bag to prevent moisture and contamination. Next, it is securely fixed within a reinforced plywood case to prevent movement and damage during transportation, given the heavy weight of the product. Finally, the plywood case, built to standard export specifications, provides sturdy protection suitable for international shipping.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.

Get in touch with us

just leave your email or phone number in the contact form so we can send you a free quote for our wide range of designs
