HPV90 Hydraulic Axial Piston Pumps For Road Roller Trucks

Axial Piston Pumps For Road Roller Trucks

Hydraulic Piston Pumps For Road Roller Trucks

HPV90 Hydraulic Pumps For Road Roller Trucks

HPV90 Hydraulic Axial Piston Pumps For Road Roller Trucks

1. High Pressure Capability: The HPV90 hydraulic axial piston pump operates efficiently under high-pressure conditions, ensuring strong and stable performance for road rollers.
2. Compact Design: Its compact and lightweight body simplifies installation and saves space in mobile hydraulic systems.
3. Excellent Efficiency: Optimized swash plate and flow control deliver maximum volumetric efficiency and reduced fuel consumption.
4. Durable Structure: Made from wear-resistant materials with precision machining for long-lasting performance even in harsh working environments.
5. Wide Compatibility: Ideal for closed-circuit hydraulic systems used in road rollers, pavers, and other heavy-duty construction machinery.

MOQ:

1 set

Packaging Details:

Plywood case

Delivery Time:

15 DAYS FOR SMALL BATCH, 60 DAYS FOR MORE THAN 100 SETS

Payment Terms:

T/T, Western Union

Supply Ability:

100 sets per month

Inquiry

Write a Review

Application

Agricultural Machinery,Walking Machinery

Characteristic

High efficiency,Smoother operation,Simple layout

Function

Hydraulic System Components

Pressure

42mpa

Brand

HIGHLAND

Operation Mode

Closed Circuit Hydraulic System

Working Medium

Hydraulic Oil

Material

Cast Iron

HPV90 Hydraulic Axial Piston Pumps For Road Roller Trucks

Highland HPV90 hydraulic axial piston pumps provide high pressure and reliable performance

for road roller trucks, ensuring smooth operation and improved efficiency in heavy-duty hydraulic systems.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Highland HPV90 hydraulic axial piston pump provides a reliable power source for road roller hydraulic systems. Designed for high pressure and variable displacement control, it delivers smooth, energy-efficient performance. Its robust build ensures long-term reliability, making it ideal for heavy-duty road construction machinery.

Product Features

Highland HPV90 hydraulic axial piston pump is a high-efficiency hydraulic component designed for road roller trucks and construction machinery.
With advanced axial piston technology, it delivers precise flow control, high volumetric efficiency, and consistent torque output under variable load conditions. Its closed-circuit design ensures smooth operation and energy savings, while hydraulic pump’s compact structure allows easy integration into mobile systems.
Built with premium materials, Highland HPV90 pump offers excellent resistance to wear and temperature fluctuations, ensuring long service life and reliability on demanding job sites.

PRODUCT INTRODUCTION

Engineered for road roller trucks, Highland HPV90 hydraulic axial piston pump offers outstanding hydraulic performance, high pressure resistance, and long-term durability. It ensures smooth, efficient, and reliable operation in closed-loop hydraulic systems used in construction and compaction equipment.

Silage Harvester Hydraulic Plunger Pumps With Volumetric Efficiency

PRODUCT SPECIFICATIONS

Rated displacement			30	50	70	90	110	130
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
Torque	Maximum output torque	Nm	227	353	480	606	749	885
Power	Continuous Power	KW	41	72	98	128	137	162
Power	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

HPV30(50)

PDF

HPV70(90)

PDF

HPV110(130)

PDF

detail displaY

HPV90 Hydraulic Piston Pumps

Hydraulic Axial Piston Pumps

Road Roller Hydraulic System

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To ensure the safe delivery of variable piston pump and hydraulic motor, we utilize multiple layers of protective packaging. The pump is first sealed in a durable plastic bag to prevent moisture and contamination. Next, it is securely fixed within a reinforced plywood case to prevent movement and damage during transportation, given the heavy weight of the product. Finally, the plywood case, built to standard export specifications, provides sturdy protection suitable for international shipping.
