Custom Hydraulic Systems For Harvesters And Heavy Machinery

Custom Hydraulic Systems For Heavy Machinery

Custom Hydraulic Systems For Harvesters And Heavy Machinery

1. Tailored Design: Each hydraulic system is custom-engineered to meet specific requirements of harvesters and heavy machinery, ensuring optimal compatibility and performance.
2. High Efficiency: Advanced hydraulic technology delivers superior energy utilization, reducing fuel consumption and improving overall productivity.
3. Robust Durability: Built with premium materials and precision components to withstand heavy loads, extreme weather, and tough working conditions.
4. Versatile Applications: Suitable for agricultural harvesters, construction equipment, and mobile machinery, supporting a wide range of hydraulic functions.
5. Easy Maintenance: Designed for simplified servicing with accessible components, minimizing downtime and extending equipment lifespan.

MOQ:

1 set

Packaging Details:

Plywood case

Delivery Time:

30-60 work days

Payment Terms:

T/T, Western Union

Supply Ability:

100 sets per month

Certificate:

CE ISO9001

Inquiry

Write a Review

Product Name

Hydraulic Transmission

Application

Agricultural Machinery,Walking Machinery

Function

Power components of hydraulic system

Type

Axial piston pump,Axial piston motor

Pressure

42mpa

Brand

HIGHLAND

Operation Mode

Closed Circuit Hydraulic System

Working Medium

Hydraulic Oil

Warranty

1 Year

Material

Cast Iron

Custom Hydraulic Systems For Harvesters And Heavy Machinery

Highland custom hydraulic systems for harvesters and heavy machinery,

offering high efficiency, durability, and reliable performance for agricultural and industrial operations.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Highland custom engineered hydraulic systems for harvesters and heavy machinery. Offering efficiency, durability, and reliable performance, these solutions are ideal for agricultural and industrial applications.

Product Features

Highland custom hydraulic systems are designed to meet the unique demands of harvesters and heavy machinery in agricultural and industrial environments.
Engineered with advanced hydraulic technology, Highland hydraulic system provide superior efficiency, reliable performance, and robust durability under the most challenging conditions.
From agricultural harvesters to heavy-duty construction machinery, Highland hydraulic systems deliver precise control, consistent power, and reduced energy consumption.

Product INTRODUCTION

Highland specialize in custom hydraulic systems designed for harvesters and heavy machinery. With a focus on energy efficiency, robust durability, and reliable performance, our systems ensure maximum productivity and long-term value in agriculture and construction.

PRODUCT SPECIFICATIONS

Rated displacement			30	50	70	90	110	130
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
Torque	Maximum output torque	Nm	227	353	480	606	749	885
Power	Continuous Power	KW	41	72	98	128	137	162
Power	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

HPV30(50)

PDF

HPV70(90)

PDF

HPV110(130)

PDF

detail displaY

Custom Hydraulic Systems

Harvester Hydraulic Solutions

Heavy Machinery Hydraulics

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To ensure the safe delivery of variable piston pump and hydraulic motor, we utilize multiple layers of protective packaging. The pump is first sealed in a durable plastic bag to prevent moisture and contamination. Next, it is securely fixed within a reinforced plywood case to prevent movement and damage during transportation, given the heavy weight of the product. Finally, the plywood case, built to standard export specifications, provides sturdy protection suitable for international shipping.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.
