Custom Closed Circuit Hydraulic Solutions For Mobile Equipment 1

Custom Closed Circuit Hydraulic Solutions For Mobile Equipment

Hydraulic Solutions For Mobile Equipment

Closed Circuit Hydraulic Solutions For Mobile Equipment

Custom Closed Circuit Hydraulic Solutions

Custom Closed Circuit Hydraulic Solutions For Mobile Equipment

Custom Design: Tailored hydraulic systems to meet specific mobile equipment requirements, optimizing performance and energy efficiency.
Closed-Circuit Efficiency: Ensures minimal energy loss, and reliable operation in demanding applications.
Durable Components: Hydraulic pumps, motors withstand heavy loads, high pressures, and long operational hours.
Versatile Applications: Suitable for construction machinery, agricultural vehicles, and other mobile hydraulic equipment.
Easy Maintenance: Modular design allows quick installation and simplified service, reducing downtime and operational costs.

MOQ:

1 set

Packaging Details:

Plywood case

Delivery Time:

30-60 work days

Payment Terms:

T/T, Western Union

Supply Ability:

100 sets per month

Certificate:

CE ISO9001

Inquiry

Write a Review

Product Name

Hydraulic Transmission

Application

Agricultural Machinery,Walking Machinery

Function

Power components of hydraulic system

Type

Axial piston pump,Axial piston motor

Pressure

42mpa

Brand

HIGHLAND

Operation Mode

Closed Circuit Hydraulic System

Working Medium

Hydraulic Oil

Warranty

1 Year

Material

Cast Iron

Custom Closed Circuit Hydraulic Solutions for Mobile Equipment

Highland custom closed circuit hydraulic solutions for mobile equipment,

delivering high performance, reliability, and energy efficiency for industrial, construction, and agricultural applications.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Highland custom closed-circuit hydraulic solutions for mobile equipment, combining durability, energy efficiency, and reliability. Designed for construction, agricultural, and industrial machinery.

Product Features

Highland provide custom closed circuit hydraulic solutions designed for mobile equipment, offering reliable and energy-efficient operation for diverse industries.
Custom hydraulic systems integrate high-quality hydraulic pumps, hydraulic motors to ensure optimal performance under heavy loads and high-pressure conditions.
Tailored designs improve efficiency, reduce energy consumption, and extend service life. Ideal for construction machinery, agricultural vehicles, and industrial mobile equipment.

Product INTRODUCTION

Highland hydraulic specialize in custom closed-circuit hydraulic systems for mobile equipment, providing high-performance pumps, motors, and valves to enhance efficiency, durability, and reliability across various industries.

PRODUCT SPECIFICATIONS

Rated displacement			30	50	70	90	110	130
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
Torque	Maximum output torque	Nm	227	353	480	606	749	885
Power	Continuous Power	KW	41	72	98	128	137	162
Power	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

HPV30(50)

PDF

HPV70(90)

PDF

HPV110(130)

PDF

detail displaY

Closed Circuit Hydraulic Solutions

Hydraulic Solutions For Mobile Equipment

Custom Hydraulic Solutions

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To ensure the safe delivery of variable piston pump and hydraulic motor, we utilize multiple layers of protective packaging. The pump is first sealed in a durable plastic bag to prevent moisture and contamination. Next, it is securely fixed within a reinforced plywood case to prevent movement and damage during transportation, given the heavy weight of the product. Finally, the plywood case, built to standard export specifications, provides sturdy protection suitable for international shipping.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.
