Closed Circuit Axial Piston Transmission Hydraulic Pumps Motors 1

Closed Circuit Axial Piston Transmission Hydraulic Pumps Motors

Closed Circuit Axial Piston Transmission Hydraulic Pumps Motors

Closed Circuit Design: Ensures stable fluid circulation and smooth power delivery for demanding applications in mobile and industrial machinery.
Axial Piston Technology: Provides high efficiency and precise control over flow and pressure.
Durable Construction: Built with high-quality materials to withstand high pressures, heavy workloads, and harsh operating conditions.
Compact & Integrated: Space-saving design allows seamless integration into hydraulic systems for easy installation.
Versatile Applications: Ideal for construction equipment, agricultural machinery, industrial machines, and other hydraulic-driven systems.

MOQ:

1 set

Packaging Details:

Plywood case

Delivery Time:

15 DAYS FOR SMALL BATCH, 60 DAYS FOR MORE THAN 100 SETS

Payment Terms:

T/T, Western Union

Supply Ability:

10 sets per month

Inquiry

Write a Review

Application

Walking Machinery,Road Machinery

Characteristic

High efficiency,Good stability

Function

Hydraulic System Components

Pressure

42mpa

Brand

HIGHLAND

Operation Mode

Closed Circuit Hydraulic System

Warranty

1 Year

Material

Cast Iron

Closed Circuit Axial Piston Transmission Hydraulic Pumps Motors

Highland closed circuit axial piston hydraulic pumps and motors designed

for efficient, precise, and reliable power transmission in industrial and mobile machinery.

our advantage

Product design

Simple and easy to disassemble and assemble, high strength and high pressure resistance, easy to install in series, full variety

Low price

We promise the lowest price for new products of the same variety in the world

Control mode

Manual servo, electric proportional servo, hydraulic servo, control valve can be replaced modularly

Simple operation

The installation interface design of the pump meets international standards and is easy to install and operate

Product Description

Highland high performance axial piston hydraulic pumps and motors with closed circuit design, offering efficient, durable, and precise power for mobile and industrial hydraulic systems.

Product Features

Highland closed circuit hydraulic system combines advanced axial piston hydraulic pumps motors to deliver precise and efficient hydraulic power in heavy-duty applications.
Its closed loop design maintains consistent fluid circulation, reducing energy loss and enhancing system reliability. Axial piston technology ensures accurate flow and pressure control, while robust construction guarantees durability under high pressures and harsh environments.
Suitable for industrial machinery, construction equipment, and agricultural systems, hydraulic solution optimizes hydraulic performance for maximum efficiency and reliability.

Product INTRODUCTION

Highland hydraulic provide closed circuit axial piston transmission hydraulic pumps and motors, engineered for high efficiency, reliability, and precise control across a wide range of industrial and mobile machinery applications.

PRODUCT SPECIFICATIONS

Rated displacement			30	50	70	90	110	130
Rated displacement	Maximum displacement	ml/r	30	50	70	90	110	130
Speed	Maximum continuous operating speed (Full load condition)	r/min	3500	3500	3200	3000	2900	2700
	Rated speed	r/min	2500
	Minimum continuous operating speed	r/min	500
Pressure	Rated working pressure	Mpa	35
	Maximum working pressure (instantaneous)	Mpa	42
	Continuous working pressure ( Δ P)	Mpa	30
	Allowable shell pressure (absolute)	Mpa	Constant0.25，Peak value0.5
Torque	Continuous output torque (Under continuous work pressure)	Nm	162.3	252.3	342.6	432.9	535.3	632.4
Torque	Maximum output torque	Nm	227	353	480	606	749	885
Power	Continuous Power	KW	41	72	98	128	137	162
Power	Maximum power	KW	57	87	105	138	159	188
Temperature	Allowable temperature of shell	℃	80
Temperature	Maximum operating temperature of fuel tank	℃	70
Angle	Maximum inclination angle of the inclined plate	°	± 18 °
Weight	HPV series hydraulic pump Hydraulic oil drainage	kg	45	46	63	64	87	87.5

HPV30(50)

PDF

HPV70(90)

PDF

HPV110(130)

PDF

detail displaY

Axial Piston Hydraulic Pumps Motors

Closed Circuit Hydraulic System

Hydraulic Transmission

Product Application

6--8 cubic meter concrete mixer truck

Cotton picker

Engineering ship pump

Underground loader

Mine use loader

Cane Grabber Machine

Packing & Delivery

To ensure the safe delivery of variable piston pump and hydraulic motor, we utilize multiple layers of protective packaging. The pump is first sealed in a durable plastic bag to prevent moisture and contamination. Next, it is securely fixed within a reinforced plywood case to prevent movement and damage during transportation, given the heavy weight of the product. Finally, the plywood case, built to standard export specifications, provides sturdy protection suitable for international shipping.

FAQ

Are you a manufacturer or Trader ?

We are a professional manufacture, we have our own R&D team and sales team, we provide one-stop service.

What is your company brand name?

Our brand name is HIGHLAND.

What is your main products?

1. Hydrostatic Pump 2. Hydrostatic Motor 3. Hydraulic test bench 4. Hydraulic tester

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is15-20 days if the goods are not in stock, it is according to customers’ quantity.

What is your terms of payment?

Payment<=10000USD,100% in advance. Payment>=10000USD, 40% T/T in advance, balance before shipment.

What is the standard of package?

Export standard package or special package according to customer requirement.
